Deyuan Marine Hot sale product-OCM-15 BILGE ALARM

Views: 57     Author: Crystal     Publish Time: 2020-06-08      Origin: Site

Deyuan Marine Hot sale product-OCM-15 BILGE ALARM

Deyuan Marine Hot sale product-OCM-15 BILGE ALARM

The OCM-15 type bilge water alarm device which is most hot sale goods and has been designed specifically for use in continuous monitoring of oil-in-bilge water, 15 ppm alarm and control of discharge, detection, memory ,printand enquiry of alarm status.

It is applicable to detect boiler condensate water. And it applies to oil and chemical industries as well.

The OCM-15 type bilge water alarm device use the technology of near infrared measurement, which can display

the detected result in real time.

The unit is supplied with 2 works-adjusted alarms.

The set point (15ppm factory set) could be adjusted at any moment through the panel.

If an alarm set point is exceed, the alarms are visible at the front panel and the appropriate relays are switched, that can be achieved the movement control of overrun closedown or the treatment of overrun recycle, and the memory and enquiry of alarm record.


Furthermore, a 4 - 20 mA (equal to 0 – 15ppm) effective signal output is available for driving a recorder or external meter.


OCM-15 type 15ppm bilge water alarm device has four 20mm filling holes and two 16mm filling holes, which the

cable takes in and reaches the wire terminal from bottom to the top. The main wire terminal of the device allows

connecting the wire of 2.5 sectional areas, and it is suggested to use the wire of 0.5-1.


A power supply of 110 to 220 VAC is available for OCM-15 type 15ppm bilge water alarm device. Only one of

the power supply should be chosen while installation. Data processing board is in the control case.

.The 15ppm device wiring details will vary dependent upon the control system to be employed but the most

frequently used systems employ alarm relay 1 for alarm only and alarm relay 2 for control purposes.
