Product Description
Ultra-High Molecular Weight Polyethylene Chemical Hose
Product Introduction:
Our UHMWPE Chemical Hose is engineered for the safe and reliable transfer of highly corrosive chemicals, including concentrated acids (sulfuric, hydrochloric, nitric), caustics, organic solvents, and aggressive industrial fluids. The ultra-smooth UHMWPE inner tube offers exceptional chemical inertness, non-stick properties, and extremely low friction, significantly reducing flow resistance and preventing scale buildup. High-tensile synthetic textile reinforcement with embedded helical steel wire provides full vacuum resistance and collapse-proof performance. The rugged EPDM or CSM outer cover delivers outstanding abrasion, ozone, UV, and weather resistance. Suitable for chemical plants, tank truck loading, marine chemical transfer, and industrial processing where standard rubber hoses fail. Temperature range: -40°C to +80°C.
Product Parameters:
| Inner | UHMWPE+EPDM |
| Cover | EPDM |
| Working Temperature | -40 ℃ ~90 ℃ |
| Safety Factor | 3:1 |
| Color | Blue, Green, Black, Etc |
| Reinforcement layer | High-strength spiral textile cord;High-strength spiral textile cord with helix steel wire |
| Application | Used for transporting corrosive media such as strong acids and alkalis,mainly used in industries such as new energy,food,pharmaceuticals,etc. |
Specification Dimensions:
| Inside Diameter | Working Pressure | Max Length | Inside Diameter | Working Pressure | Max Length | ||
| mm | inch | bar | m | mm | inch | bar | m |
| 19 | 3/4" | 10~20 | 40 | 19 | 3/4" | 10~20 | 40 |
| 25 | 1" | 10~20 | 40 | 25 | 1" | 10~20 | 40 |
| 32 | 1-1/4" | 10~20 | 40 | 32 | 1-1/4" | 10~20 | 40 |
| 38 | 1-1/2" | 10~20 | 40 | 38 | 1-1/2" | 10~20 | 40 |
| 51 | 2" | 10~20 | 40 | 51 | 2" | 10~20 | 40 |
| 64 | 2-1/2" | 10~20 | 40 | 64 | 2-1/2" | 10~20 | 40 |
| 76 | 3" | 10~20 | 40 | 76 | 3" | 10~20 | 40 |
| 102 | 4" | 10~20 | 40 | 102 | 4" | 10~20 | 40 |
| 152 | 6" | 10~20 | 40 | ||||
| Note:Specifications,pressures,colors,etc.can be customized according to requirements | |||||||
Key Features:
1.Exceptional Chemical Resistance – The UHMWPE inner tube provides outstanding resistance to a wide range of chemicals, including strong acids (e.g., sulfuric acid, hydrochloric acid), caustic solutions, hydrocarbons, and organic solvents, ensuring long service life even in harsh environments.
2.Superior Abrasion Resistance – UHMWPE has one of the highest abrasion resistance ratings among thermoplastics, making this hose ideal for transferring slurries, fine particles, or other abrasive media without premature wear.
3.Ultra-Low Friction Coefficient – The smooth, non-stick inner surface minimizes pressure loss and flow resistance, while preventing material buildup or clogging – a critical advantage for high-purity or viscous chemical transfer.
4.Broad Temperature Range – Suitable for use from -40°C to +80°C (-40°F to +176°F), depending on the specific chemical and construction, allowing reliable operation in extreme conditions.
5.Lightweight & Flexible – Compared to rubber hoses of similar pressure rating, the UHMWPE chemical hose is significantly lighter and more flexible, reducing operator fatigue and improving handling efficiency.
6.Reinforced Construction – Typically reinforced with high-strength synthetic textile layers and a helix wire (e.g., galvanized or stainless steel) for full vacuum resistance, kinking prevention, and static dissipation.
