Product Description
Large Diameter Rubber Hose
Product Introduction:
Our Large Diameter Rubber Hose is a heavy-duty, high-performance solution designed for the efficient and safe transfer of a broad spectrum of materials across various industries. Whether you need to convey air, water, hydraulic oil, diesel, gasoline, crude oil, slurry, bulk materials, or even corrosive media, this hose delivers reliable operation under demanding conditions.
Superior Material Customization
To meet specific application requirements, we offer flexible material selection. Depending on the medium being transferred, we can choose different rubber compounds — such as oil-resistant NBR, abrasion-resistant NR/SBR, acid/alkali-resistant EPDM, or high-temperature-resistant materials. This ensures optimal chemical compatibility, extended service life, and operational safety.
Process Design for Real-World Needs
We understand that each customer's operating environment is unique. Therefore, we not only select the appropriate compound but also customize the hose construction process — including reinforcement layers (textile or steel wire), pressure ratings, temperature ranges, and inner tube smoothness — to match your exact needs.
Flanged Hose Customization
In addition to standard hoses, we can produce various types of flanged rubber hoses to facilitate easy, secure flange connections. The flange materials (carbon steel, stainless steel, etc.), as well as flange standards (ANSI, DIN, JIS, BS, etc.), can all be manufactured according to customer specifications. This makes installation and replacement simple and compatible with your existing piping systems.
Specification Dimensions:
| Inside Diameter | Working Pressure | Max Length | |
| mm | inch | bar | m |
| 200 | 8 | 10~20 | 11.8 |
| 250 | 10 | 10~20 | 11.8 |
| 300 | 12 | 10~20 | 11.8 |
| 350 | 14 | 10~20 | 11.8 |
| 400 | 16 | 10~20 | 11.8 |
| 450 | 18 | 10~20 | 11.8 |
| 500 | 20 | 10~20 | 11.8 |
| 600 | 24 | 10~20 | 11.8 |
| 800 | 32 | 10~20 | 11.8 |
| 1100 | 44 | 10~20 | 11.8 |
| Note:Specifications,pressures,colors,etc.can be customized according to requirements | |||
Typical Applications：
*Industrial water supply and drainage
*Hydraulic systems and oil transfer
*Fuel handling for diesel, gasoline, and crude oil
*Slurry and mud discharge in mining and dredging
*Pneumatic conveying of bulk solids (powders, granules)
*Chemical and corrosive fluid transfer
With a strong focus on durability, safety, and customization, our large diameter rubber hoses are trusted by engineers and procurement professionals worldwide. Contact us to discuss your specific requirements.
