Product Description
EPDM High Temperature Steam Hose
Product Introduction:
The EPDM High Temperature Steam Hose is a premium-grade industrial hose engineered for the safe, efficient, and long-lasting transfer of saturated and superheated steam. Utilizing EPDM (Ethylene Propylene Diene Monomer) rubber as the core material, this hose delivers exceptional heat resistance, aging resistance, and chemical compatibility, making it the preferred choice for demanding applications in the chemical, petrochemical, metallurgical, and energy industries.
EPDM rubber inherently exhibits outstanding resistance to hot water, steam, oxidation, and polar chemicals, while maintaining flexibility even under extreme temperature fluctuations. The inner tube is specially formulated to resist swelling, cracking, and scaling caused by continuous steam exposure. Multiple layers of high-tensile steel wire or textile reinforcement provide superior burst strength and kink resistance, ensuring stable operation under high-pressure steam transfer conditions.
The outer cover is designed to withstand harsh industrial environments, offering excellent resistance to abrasion, ozone, UV radiation, oil splashes, and weathering. This robust construction ensures a long service life and reduces downtime for replacement.
Product Parameters:
| Inner | EPDM |
| Cover | EPDM |
| Working Temperature | -30 ℃ ~210 ℃ |
| Safety Factor | 3:1 |
| Color | Black |
| Reinforcement layer | high-tensile steel wire spiral |
| Executive Standard | HGT3036-2009 |
| Characteristic | High temperature steel wire steam hoses have excellent heat resistance and compression resistance, which can maintain stable and safe operation in extreme environments. In addition, this product also has anti-static function, which can effectively reduce the danger of static electricity generation and ensure the safety of the production process. |
| Application | Widely used in industries such as chemical,petroleum,metallurgy,and energy. |
Specification Dimensions:
| Nominal Diameter | Inside Diameter | Outer Diameter | Working Pressure | Burst Pressure | ||
| mm | inch | Min | Max | mm | MPa | MPa |
| 19 | 3/4" | 18.6 | 19.8 | 30.2 | 16 | 48 |
| 25 | 1" | 25.0 | 26.4 | 38.9 | 16 | 48 |
| 32 | 1-1/4" | 31.4 | 33 | 49.6 | 16 | 48 |
| 38 | 1-1/2" | 37.7 | 39.3 | 56 | 10 | 30 |
| 51 | 2" | 50.4 | 52 | 68.6 | 10 | 30 |
| Note:Specifications,pressures,colors,etc.can be customized according to requirements | ||||||
Key Features:
*Withstands continuous steam temperatures from -30°C up to +210°C
*Compatible with both saturated and superheated steam
*Excellent resistance to steam-induced swelling and degradation
*High tensile reinforcement for burst and pressure safety
*Smooth EPDM inner tube minimizes flow resistance and scaling
*Abrasion, ozone, and weather-resistant outer cover
*Flexible and easy to handle, even at high temperatures
