Product Description
Marine RDHL Floater Level Switch
Product Introduction:
The Marine Floater Level Switch is a simple, reliable, and cost‑effective device used for point level detection in shipboard tanks. It provides a discrete switching signal (open/close) when the liquid level reaches a preset high or low point. Designed for harsh marine environments, this switch is widely used on oil tankers, bulk carriers, container ships, and offshore platforms for alarm and pump control applications.
Main Technical Specification:
| Nominal press(PN) | 0.6MPa，1.0MPa，1.6MPa |
| Medium Visidity | 0.02Pa.S |
| Explosion degree | Ex ia lIC T3~6 |
| Medium density | ≥0.45g/cm³ |
| Output signal | switch,resistance value |
| Protection class | IP56/IP68 |
| Type approval | CCS, DNV-GL, NK, BV, RINA, ABS |
Characteristic：
*The working range of the sensor: -40°C~+85°C;High temperature type: -25°C~+125°C;
*Electromagnetic compatibility design, anti-surge, anti-pulse, anti-static,Anti-voltage instantaneous drop;
*Simple structure, convenient installation, reliable operation, simple maintenance and high pressure resistance;
*Anti-liquid fluctuation design, stainless steel protective sleeve can be added;
