Marine Radar Type Level Transmitter

Marine Radar Type Level Transmitter

Product Introduction:

The radar type tank level tansmitter can be used for continuous liquid level measurement. Its principle is that the probe emits continuous pulses and receives the signals reflected by the liquid level. By measuring the time between the emission and the return, the distance of the liquid level can be calculated and converted into output signals.

Application：

The radar type tank level tansmitter is suitable for non-contact continuous liquid level measurement of oil tanks and chemical carriers, and also suitable for liquid level monitoring of other tanks and oil production platforms. The measurement results are not affected by the type of medium in the tank, temperature change, gas or water vapor coverage.

Main Technical Specification:

Characteristic：

*The measuring range can reach 35 meters;

*The medium temperature can reach 400°C, the pressure can reach 100bar;

*All-weather and solid instrument shell minimizes the possibility of instrument damage;

*Not affected by temperature change, high pressure, concentrated gas or stratified gas, noise or strong airflow, dust or steam;
