Product Description
Explosion-Proof Trolley
Product Introduction:
The Explosion-Proof Trolley is a manual traveling device designed for use with hand chain hoists in hazardous environments. Made from copper alloy materials including aluminum bronze and beryllium bronze, this trolley prevents sparks during operation.
Key Features:
*No sparks – Copper alloy wheels and frame avoid friction sparks.
*Manual push type – Easy to move by hand along I-beam rails.
*Rust proof – Special coating for long life in harsh sites.
*Adjustable fit – Works with various beam widths.
*Safe design – No electric parts, ideal for gas and dust zones.
*Light weight – Easy to carry and install.
Product Parameters：
| (PUSH TYPE) | (PUSH TYPE) | ||||||
| Capacity(T) | Lifting Height(m) | I-beam Width (mm) | Weight (kg) | Capacity(T) | Lifting Height(m) | I-beam Width (mm) | Weight (kg) |
| 0.5 | 2.5 | 68-94 | 12.5 | 0.5 | 2.5 | 68-94 | 16.5 |
| 1 | 2.5 | 68-100 | 14.5 | 1 | 2.5 | 68-100 | 20.0 |
| 2 | 2.5 | 94-124 | 22.3 | 2 | 2.5 | 94-124 | 26.0 |
| 3 | 3 | 116-140 | 24 | 3 | 3 | 116-140 | 27.5 |
| 5 | 3 | 142-180 | 34 | 5 | 3 | 142-180 | 34 |
| 10 | 3 | 142-180 | 68 | 10 | 3 | 142-180 | 68 |
| 16 | 3 | 142-180 | 170 | 16 | 3 | 142-180 | 170 |
| 20 | 3 | 142-180 | 170 | ||||
Deyuan Marine provides one-stop sourcing services and offers tailor-made products on request.
