Product Description
Marine Stainless Steel Swivel CB/T 178-96 Chain Stopper Type A for Sales
Marine Swivel Type Chain Stopper plays an important role in Marine mooring application .
CCS Swivel CB/T 178-96 Chain Stopper Type A is the special type of anchor chain stopper and widely use in our vessel .The Swivel CB/T 178-96 Chain Stopper Type A disposes between the joining tube and anchor windlass . Type A Swivel CB/T 178-96 Chain Stopper prevents the chain from slip out .Then can protect our vessel .
Deyuan Marine Swivel CB/T 178-96 Chain Stopper Type A made by stainless steel with the tight quality and excellent working performance .Stainless Steel Swivel Chain Stopper Type A combines by chain hook, screw and telescopic chains .Stainless Steel CB/T 178-96 Chain Stopper Type A fix the anchor on the deck when we use the chain hook on the horizontal chain link and tight the screws stretching the chain .
Many sizes and Good price Swivel Chain Stopper Type A we can supply and the Swivel CB/T 178-96 Chain Stopper Type A for Sales now .Below is the data of Marine Usage Swivel CB/T 178-96 Chain Stopper Type A for your reference .
| Anchor chain dia. | 22-26 | 28-32 | 34-38 | 40-44 | 46-48 | 52-58 | 60-66 |
| B | 280 | 310 | 360 | 420 | 480 | 550 | 640 |
| C | 190 | 210 | 250 | 290 | 330 | 380 | 440 |
| H | 335 | 400 | 455 | 515 | 585 | 680 | 775 |
| L | 500 | 550 | 600 | 670 | 770 | 970 | 1000 |
| L1 | 275 | 330 | 375 | 430 | 480 | 565 | 640 |
| L2 | 265 | 320 | 365 | 415 | 465 | 545 | 615 |
| Weight(kg) | 90 | 122 | 163 | 238 | 353 | 518 | 772 |
