Product Description
Hydraulic Steel Wire Rope Press Machine
Product Introduction:
Designed specifically for demanding marine and offshore environments, the H150–H500 Hydraulic Steel Wire Rope Press Machine represents a new generation of precision rope-splicing equipment. Developed in response to global market trends, this series combines advanced hydraulic technology with rugged, compact construction to deliver consistent, high-quality rope terminations—even in confined shipboard spaces.
Precision & Structural Integrity:
The H-series utilizes a refined pressing process that ensures exact dimensional control over every termination. Its streamlined structure minimizes footprint while maximizing rigidity, making it ideal for installation on vessels, rigs, and dockside workshops where space is at a premium. The heavy-duty steel frame and precision-ground dies guarantee repeatable accuracy, producing splices that meet or exceed international load-testing standards.
Technical Specifications:
| Model | H150 | H200 | H300 | H500 | |
| MAX.force | KN | 1500 | 2000 | 3000 | 5000 |
| MAX.dia.in one pressing | mm | φ16 | φ20 | φ28 | φ38 |
| MAX.dia.with multi bite pressing | mm | φ18 | φ22 | φ32 | φ40 |
| MAX.piston movement | mm | 60 | 80 | 140 | 140 |
| Piston working movement | mm | 40 | 50 | 60 | 90 |
| MAX.working pressure | Mpa | 30 | 28 | 28 | 45 |
| The up speed of piston | mm/sec | 1.8 | 4.4 | 5.3 | 5.3 |
| The down speed of piston | mm/sec | 3.2 | 6 | 8.8 | 8.8 |
| Color | Blue、Green | ||||
| Type | Gantry、Steel Casting | ||||
Key Performance Benefits For Marine Applications:
1.High Joint Strength & Safe Working Load – Pressed terminations achieve near 100% rope efficiency, providing reliable holding power for mooring, towing, lifting, and cargo handling.
2.Smooth, Corrosion-Resistant Finish – The cold-forming process leaves a clean, uniform sleeve surface that resists saltwater corrosion and minimizes snagging on sheaves or fairleads.
3.Cost-Effective Rope Usage – Unlike socketing or wedging, the pressing method eliminates wire waste and allows for precise length control, reducing overall rigging costs over time.
4.Compact Operation in Tight Spaces – The machine’s ergonomic design and side-entry pressing action enable safe, efficient work in low-headroom or narrow-access areas—a common challenge in engine rooms, decks, and offshore platforms.
5.High-Efficiency Workflow – With rapid cycle times and user-friendly controls (manual or semi-automatic options), the H150–H500 significantly boosts productivity for both routine maintenance and emergency repairs.
Versatile Industrial Coverage:
While optimized for marine use, this press machine also excels in power generation, mining, construction, oil & gas, port logistics, and subsea engineering. The H150 model handles rope diameters up to 150 mm, while the H500 accommodates larger cables—offering a scalable solution for light to heavy lifting operations.
