CPL-190 Vertical Magnetic Compass

  • Deyuan Marine

Product Description

CPL-190 Vertical Magnetic Compass
CPL-190vertical Magnetic Compass is a sort of class A transparent liquid magnetic compass. It is designed and manufactured in accordance with the national standard GB/T 14108-2011 (General Technical Terms of Marine Magnetic Compass Class A ). The magnetic compass is suitable for the large and middle vessels acting as standard compass or steering compass and is used for measuring azimuth and indicating course heading. The product has the advantages of high precision、convenient correcting difference 、steady performance and legible lighting etc.
Main technical parameters :
Project Data
Dial Diameter Φ190mm
Dial graduation 360° 1°for each grid
Using temperature -25~+60
Indicating deviation     H=35μTT=20±3℃) ≤0.5°
Half periodH=35μTT=20±3℃) ≥8.62 S
Friction deviationH=35μTT=20±3℃) ≤0.09°
Main semicircle self heterodyne correcting energy 45°
Secondary semicircle self heterodyne correcting energy 6°(magnetic inclination Q=45°)
Quadrant self heterodyne correcting energy 0.5°10°
Inclining self heterodyne correcting energy 75~+75μT
Lighting power supply AC 220VDC 24V
Outline Dimension 720×430×1300mm
Diameter of mounting holes Pitchrow 420 ApertureΦ16
Weight 40kg
