Product Description
YPK-03-C Diaphragm Type Pressure Controller
Product Introduction:
The YPK-03-C Marine Diaphragm Type Pressure Controller is a precision electromechanical control device specifically engineered for shipboard pressure monitoring and control applications. Designed to operate with water, oil, gas, and steam media, this controller provides reliable two-position (on/off) control for motor control circuits and signal alarm systems, maintaining system pressure within a preset range .
Main Technical Specification:
| Model | Control range(MPa) | Accuracy(MPa) | Contact Capacity |
| YPK-03-C-01 | 0.1~0.5 | ±0.02 | AC380V15A two contacts |
| YPK-03-C-02 | 0.1~1.2 | ±0.04 | |
| YPK-03-C-03 | 0.6~3 | ±0.1 |
