Product Description
Pedestal Fairleads Eight, Nine or Ten-roller Fairlead DIN Standard With Good Price
Pedestal Fairleads are designed for mounting free on deck, and welding into the bulwark, and a rope turn of 90°.
According to DIN(German standard), there are four roller fairleads, five roller fairleads, six roller fairleads, the biggest one is with 12 rollers fairleads. Different fairleads with different rollers are suitable for different wire rope or rope diameter.
Type | A | B | C | D | E | F | G | H | I | K | L | M | N | weight (kg) |
CDFL2 CDFM2 CDFR2 CDFA2 CDFLM2 CDFT2 | 180 | 100 | 914 | 80 | 710 | 170 | 10 | 465 | 208 | 80 | 356 | 255 | 620 | 147 147 147 159 159 159 171 |
CDFL3 CDFM3 CDFR3 CDFA3 CDFLM3 CDFRM3 CDFT3 | 230 | 130 | 1132 | 100 | 878 | 210 | 10 | 575 | 258 | 100 | 356 | 315 | 778 | 222 222 222 244 244 244 266 |
CDFL5 CDFM5 CDFR5 CDFA5 CDFLM5 CDFRM5 CDFT5 | 250 | 130 | 1272 | 120 | 998 | 250 | 15 | 655 | 308 | 120 | 506 | 375 | 878 | 377 377 377 414 414 414 451 |
CDFL8 CDFM8 CDFR8 CDFA8 CDFLM8 CDFRM8 CDFT8 | 280 | 160 | 1420 | 140 | 1136 | 288 | 20 | 730 | 328 | 120 | 576 | 436 | 996 | 509 509 509 561 561 561 613 |
CDFL12 CDFM12 CDFR12 CDFA12 CDFLM12 CDFRM12 CDFT12 | 300 | 160 | 1678 | 180 | 1314 | 366 | 25 | 855 | 398 | 140 | 676 | 549 | 1154 | 1015 1015 1015 1100 1100 1100 1185 |
CDFL20 CDFM20 CDFR20 CDFA20 CDFLM20 CDFRM20 CDFT20 | 320 | 180 | 1916 | 245 | 1596 | 500 | 35 | 1045 | 505 | 180 | 830 | 750 | 1396 | 1820 1820 1820 1990 1990 1190 2160 |
CDFL32 CDFM32 CDFR32 CDFA32 CDFLM32 CDFRM32 CDFT32 | 400 | 250 | 2400 | 300 | 1936 | 608 | 45 | 1260 | 583 | 200 | 1016 | 912 | 1716 | |
German Standard ten eleven or twelve -Roller Fairlead | ||||||||||||||
Type | A | B | C | D | E | F | G | H | I | K | L | M | N | weight (kg) |
CDFGL2 CDFGM2 CDFGR2 CDFGA2 CDFGLM2 CDFGT2 | 180 | 100 | 914 | 80 | 710 | 170 | 10 | 510 | 253 | 125 | 356 | 255 | 620 | 181 181 181 193 193 193 205 |
CDFGL3 CDFGM3 CDFGR3 CDFGA3 CDFGLM3 CDFGRM3 CDFGT3 | 230 | 130 | 1132 | 100 | 878 | 210 | 10 | 625 | 308 | 150 | 446 | 315 | 778 | 282 282 282 304 304 304 326 |
CDFGL5 CDFGM5 CDFGR5 CDFGA5 CDFGLM5 CDFGRM5 CDFGT5 | 250 | 130 | 1272 | 120 | 998 | 250 | 15 | 710 | 363 | 175 | 506 | 375 | 878 | 471 471 471 508 508 508 545 |
CDFL8 CDFM8 CDFR8 CDFA8 CDFLM8 CDFRM8 CDFT8 | 280 | 160 | 1420 | 140 | 1136 | 288 | 20 | 825 | 423 | 215 | 576 | 436 | 996 | 637 637 637 689 689 689 741 |
CDFGL12 CDFGM12 CDFGR12 CDFGA12 CDFGLM12 CDFGRM12 CDFGT12 | 300 | 160 | 1678 | 180 | 1314 | 366 | 25 | 975 | 518 | 260 | 676 | 549 | 1154 | 1217 1217 1217 1302 1302 1302 1387 |
CDFL20 CDFM20 CDFR20 CDFA20 CDFLM20 CDFRM20 CDFT20 | 320 | 180 | 1916 | 245 | 1596 | 500 | 35 | 1200 | 660 | 335 | 830 | 750 | 1396 | 2210 2210 2210 2380 2380 2380 2550 |
CDFGL32 CDFGM32 CDFGR32 CDFGA32 CDFGLM32 CDFGRM32 CDFGT32 | 400 | 250 | 2400 | 300 | 1936 | 608 | 45 | 1465 | 788 | 405 | 1016 | 912 | 1716 |
