Product Description
CB3015 Engineering Fairlead for Dredger
Introduction of CB3015 Engineering Fairlead for Dredger
As the name indicates, CB3015 fairlead is a kind of mooring fitting that specially designed for engineering project,
use for dredger, floating pile driver. There are 2types in total, Type A & Type B, both types come with five sizes,100mm, 150mm, 200mm, 250mm, 300mm.
Apart from Engineering Fairlead, DEYUAN MARINE also offer other universal marine fairleads to suit different jobs
ISO13733 Universal Roller Fairlead with upper roller
ISO13742 Universal Roller Fairlead without upper roller
JIS F2020 Deck End Rollers
JIS F 2026-80 Universal Fairlead Rollers, type A
JIS F 2026-80 Universal Fairlead Rollers, type BR
DIN81902 Universal Fairlead Rollers, type FA4
DIN81902 Roller Fairleaders, type FA6
DIN81902 Roller Fairleaders, type FB7
DIN81902 Roller Fairleader, type FB10
CB/T 3062 Fairlead Roller
CB/T 3139 St.Lawrene Roller
CB3015 Engineering Fairlead for Dredger
Roller Dia. | Horizontal Roller Dia. | Wire Dia. | L | B | H | b | h1 | h2 | screw hole dia. | |
(D) | (D1) | A | B | |||||||
100 | 85 | 19.5 | 540 | 340 | 240 | 240 | 250 | 220 | 50 | 22 |
150 | 120 | 26 | 760 | 460 | 340 | 340 | 340 | 320 | 65 | 26 |
200 | 150 | 37.5 | 980 | 580 | 430 | 440 | 430 | 410 | 80 | 32 |
250 | 200 | 48.5 | 1220 | 740 | 520 | 550 | 540 | 500 | 110 | 39 |
300 | 250 | 56 | 1460 | 900 | 620 | 675 | 650 | 590 | 135 | 39 |
