JIS F 2014-1987 Pedestal Fairleads Cleat Fairlead With Single Roller A Type
Standard Features of Fairlead With Single Roller:
1. This Cleat Fairlead with Heavy Duty Steel Rollers
2. Oil Impregnated Bronze Bushings (No Grease Required)
3. Alloy Steel Shafts with Bolt-In-Place Keeper Tabs
4. All Steel Frame Construction and Weld Down Base Plate
5. Designed For Daily Use In Harsh Environment
6. White Blasted and Coated With Blue Marine Duty Paint
Optional Features of JIS F 2014-1987 Pedestal Fairleads:
1. Stainless Steel Shafts and Hardware
2. Sealed Roller Bearings
3. Various Roller Materials for Special Applications
4. Bolt Down Style Base Plate
5. Additional Rollers and Configurations
6. Special Primers and Paints / Coatings
7. Other models available: mthree roller fairleads, four roller fairleads, five or more roller fairleads, etc.
| ROLLER DIA (mm) | Wire Rope's Maximum Diameter(mm) | Outline Dimension(mm) | Weight of roller (kg) | Weight of Base(kg) H1=1000 | ||||||||||||||||||
| Tensile Strength1550N/mm² | hemp rope | synthetic fiber rope | D1 | D2 | D3 | D4 | D5 | L≈ | H | H1 | H2 | H3 | S | t | t1 | cast iron (HT) | cast steel (ZG) | |||||
| 6×24 | 6×30 | 6×37 | ||||||||||||||||||||
| 150 | 17 | 17.5 | 15 | 45 | 32 | 240 | 270 | 90 | 71 | 60 | 245 | 211 | 40 | 75 | 3 | 12 | 8 | 32.1 | 33.8 | 129 | ||
| 200 | 22.5 | 21.5 | 19.5 | 55 | 40 | 310 | 340 | 115 | 95 | 80 | 285 | 251 | 50 | 85 | 3 | 14 | 10 | 64.6 | 68 | 178 | ||
| 250 | 24 | 26 | 24 | 65 | 45 | 380 | 410 | 140 | 107 | 90 | 323 | 298 | 60 | 100 | 4 | 14 | 10 | 108 | 114 | 207 | ||
| 300 | 30 | 32.5 | 28 | 70 | 50 | 440 | 470 | 160 | 127 | 110 | 355 | 321 | 60 | 100 | 4 | 16 | 14 | 159 | 168 | 265 | ||
| 350 | 37.5 | 39 | 34.5 | 75 | 55 | 500 | 530 | 180 | 144 | 125 | 390 | 346 | 65 | 100 | 4 | 18 | 14 | 235 | 248 | 332 | ||
| 400 | 41 | 39 | 39 | 85 | 65 | 560 | 590 | 200 | 161 | 140 | 420 | 371 | 70 | 100 | 5 | 20 | 16 | 336 | 355 | 401 | ||
