Hydraulic Driven Offshore Dock Marine Folding Type Crane

Place of Origin: China (Mainland)
Brand Name: Deyuan
Driven: Hydraulic
SWL:1-10T
Out-reach:10-15m
Hoist Speed:8~15m/min
Luffing Time:60~80sec
Slewing Speed:0.5 r/min
Condition: New
Customized: Accept
Transport Package: Export standard
Certificate: CCS, BV, ABS, DNV, KR, NK, RINA, GL, LR
  • Deyuan Marine

Availability:

Product Description

Hydraulic Folding Crane

Type SWL Out-reach Hoist Speed Luffing Time Slewing Speed Power REQ.
(T) (m) (m/min) (sec) (r/min) (KW)
HFC1/10 1 10 8~15 60~80 0.5 11
HFC1/15 1 15 8~15 60~80 11
HFC2/10 2 10 8~15 60~80 15
HFC2/15 2 15 8~15 60~80 15
HFC3/10 3 10 8~15 60~80 18.5
HFC3/15 3 15 8~15 60~80 18.5
HFC4/10 4 10 8~15 60~80 22
HFC4/15 4 15 8~15 60~80 22
HFC5/10 5 10 8~12 70~100 30
HFC5/15 5 15 8~12 70~100 30
HFC8/15 8 15 8~12 70~100 45
HFC10/15 10 15 8~12 70~100 55

More hydraulic folding crane can be offered,pls contact us for more details.
