CCS Marine Fairlead Five-Roller Type BR JIS F 2026-80

Brand:Deyuan Marine
Name: Fairlead Five-Roller
Standard: JIS F 2026-80
Material: Cast iron or cast steel
Roller No.: five
Warranty : 2years
Certificate: CCS,ABS,RINA,LR,BV,DNV etc
Payment:L/C,T/T etc
Orgin:China
  • Name: Fairlead Five-Roller
  • Standard: JIS F 2026-80
  • Material: Cast iron or cast steel
  • Roller No.: five
  • Warranty : 2years
  • Certificate: CCS,ABS,RINA,LR,BV,DNV etc
Availability:

Product Description

CCS Marine Fairlead Five-Roller Type BR JIS F 2026-80
Roller fairleads play an important role at ship's mooring and towing operation.Mainly to maintain tension and straightness of the rope or wire rope and to reduce the lateral load tension on the winch.
This roller fairleads is designed and strictly fabricated according to the standard of JIS F2026-80,there are two types,one is type A,the other one is type B.Both type can offer CCS,ABS,DNV,RINA,LR etc certificate,pls donot hesitate to contact us if you are interested.



Deyuan Marine fairlead roller data for your reference :

Nominal
 Dia.
Frame
B B1 b b1 b2 b3 b4 D D1 D2 D3 H h h1 h2 h3 L L1
140 310 390 150 69 20 45 25 90 140 120 80 480 275 130 40 50 515 805
160 360 460 175 82 22 65 35 110 160 140 90 515 290 145 45 60 570 890
180 410 525 200 95 24 80 40 135 180 150 100 560 315 155 50 70 620 960
200 460 583 225 108 26 90 45 160 200 160 110 590 330 170 60 80 675 1049
250 565 701 280 133 30 105 55 200 250 200 130 715 415 195 75 90 825 1303
315 670 824 330 159 34 125 65 240 300 240 160 870 520 220 90 100 980 1562


Nominal
 Dia.
Frame Leg of weld weight
(kg)
l l1 l2 l3 l4 R R1 t t1 t2 t3 t4 f f1 f2 f3
140 335 120 60 50 20 40 70 12 10 16 6 20 9 6 12 4 235
160 365 135 65 50 20 45 85 14 10 18 8 22 9 7 12 6 353
180 390 145 70 50 20 50 95 16 10 20 10 24 9 9 12 8 496
200 420 160 80 50 20 60 110 18 12 22 10 26 10 10 14 8 648
250 520 210 105 60 25 75 135 20 14 26 12 30 10 12 14 10 1176
315 620 260 130 60 25 90 160 22 16 30 14 34 12 14 16 10 2050
