Marine Open Type Chock CB/T38-99 Ship Mooring Fairlead Chock Type B
Product Description
1. There are closed type, open type, non-rollers type, belt rollers types Chocks and so on.
2. Fairlead chock is casting, which has two kinds of integral and modular. Medium-sized vessels are used with a wheel chock which can reduce wear and tear on the mooring.
3. Mooring Fairlead Chock Type B is usually put on the bulwark or deck of the tanker, tugboat or other types of vessel.
Features
1. High quality and competitive price.
2. Various sizes can be provided.
3. With ABS, BV, CCS and other specified certificates.
Parameters
| Nominal size | Chain′s MB(kN) | Max.dia.of chain | Body | Roller | Roller axle d | ||||||||||
| Steel wire | Synthetic fiber rope | L | B | I | I1 | I2 | b | h1 | D | D1 | H1 | ||||
| 6×24 | 6×37 | ||||||||||||||
| 75 | 23.3 | 7.4 | - | 12 | 400 | 150 | 150 | 80 | 125 | 75 | 70 | 75 | 120 | 64 | 22 |
| 100 | 52.5 | 11 | - | 18 | 530 | 200 | 200 | 105 | 165 | 100 | 92 | 100 | 160 | 86 | 32 |
| 125 | 93.4 | 15 | - | 24 | 650 | 250 | 250 | 126 | 200 | 125 | 108 | 125 | 200 | 102 | 40 |
| 150 | 145.8 | 18.5 | - | 30 | 780 | 300 | 300 | 150 | 240 | 150 | 126 | 150 | 240 | 120 | 50 |
| 200 | 246.6 | 24 | - | 40 | 1100 | 370 | 400 | 191 | 300 | 200 | 161 | 200 | 310 | 154 | 63 |
| 250 | 373.6 | 30 | - | 48 | 1240 | 470 | 500 | 239 | 370 | 240 | 191 | 250 | 400 | 184 | 75 |
| 300 | 472.7 | 33.5 | - | 56 | 1480 | 550 | 600 | 284 | 440 | 290 | 231 | 300 | 480 | 224 | 90 |
| 350 | 583.5 | 37.5 | 34.5 | 64 | 1690 | 640 | 690 | 322 | 500 | 340 | 251 | 350 | 560 | 244 | 100 |
