Product Description
Marine Type A Aluminum Honeycomb Wall Panel
Product Introduction:
The Marine Type A Aluminum Honeycomb Wall Panel is a lightweight, high-strength composite panel specifically engineered for marine and offshore applications, including cruise ships, ferries, yachts, offshore platforms, and naval vessels. Featuring a Type A construction (steel facer on both sides or aluminum facer over a honeycomb core — note: Type A in marine context typically requires steel facers; for all-aluminum honeycomb panels, certification may vary — see clarification below), this panel delivers exceptional rigidity, impact resistance, and fire performance while significantly reducing weight compared to traditional rock wool or solid steel panels.
Product Parameters:
| Type | P3 | L5 | L6 |
| Fire Class | B-15 | B-0 | B-0 |
| Sound Reduction | / | / | / |
| Weight | 13.1kg/m² | 12.4kg/m² | 12.2kg/m² |
| Thickness | 50mm | 30mm | 25mm |
| Core material | TC Plate+ Alu.honeycomb | Alu.honeycomb | |
| Surface finish | PVC film/Powder painted+Galvanized steel plate PVC film/Powder painted+Aluminum plate | ||
| Dimension | Thickness×550mm Width×Required Length(Max 3000mm) | ||
| Tolerances | Width (-1,0),Height±3,Thickness(-1,0) | ||
Core Material – Aluminum Honeycomb:
The core consists of a hexagonal aluminum honeycomb structure, manufactured from corrosion-resistant 3000 or 5000 series aluminum alloy. This geometric configuration provides an exceptional strength-to-weight ratio, offering the rigidity of a solid panel at a fraction of the weight. Key advantages include:
*Ultra-lightweight – 40–60% lighter than rock wool panels of equal thickness.
*High compressive strength – Resists crushing and point loads.
*Energy absorption – Excellent impact and vibration damping.
*Non-rotting & non-hydroscopic – No moisture absorption or mold growth.
Deyuan Marine is dedicated to providing personalized guidance and support, empowering you to make informed decisions that are perfectly aligned with your unique needs.
