Product Description
Marine Portable Hermetic Sampler
Product Introduction:
The Marine Portable Hermetic Sampler is a specialized sampling device designed for the safe and representative collection of liquid cargo samples from oil tankers, chemical carriers, and petrochemical barges. Unlike traditional "thief" samplers that expose the operator and environment to toxic vapors, the hermetic sampler operates as a completely sealed system, preventing the release of volatile organic compounds (VOCs) and hazardous gases. It fully complies with MARPOL Annex I, IMO Circulars, and industry standards such as ASTM D4057 (Manual Closed Sampling) and ISO 3170.
RDHS-100/200 closed sampler is suitable for sampling in ship cabins, tanks and other liquid tanks with clear stratification and various non-corrosive liquid media.
Technical Specifications:
| Type | portable |
| Tape measure specification | metric roll |
| Length of ruler | 15m,30m |
| Minimum dividing value | 1mm |
| Liquid level height of sampling medium | ≥100mm |
| Sampling medium density range | 0.6~3.5g/cm³ |
| Medium temperature range | -25~110°C |
| Overall dimensions | 1150X270X180mm |
Deyuan Marine provides one-stop sourcing services and offers tailor-made products on request.
