Product Description
M2950 Waterproof and Drop-proof Rifle Long Gun Carrying Cases
The M2950 is waterproof and drop-resistant, with EVA sponge inside, suitable for Type 88/95 gun cases, and can hold up to 4 guns. The upper cover is for magazine, which can be loaded with up to 10 pieces.
EVA sponges have different hardness properties, and materials can be selected according to customer requirements when customizing.
Feature:
Waterproof and dustproof, automatic adjustment of internal and external pressure, impact resistance, low temperature resistance, deformation resistance
| Product Name | Gun Case, Magazine Case |
| Protective box material | professional engineering plastics modified polypropylene PP |
| Protective box color | black/green/customizable |
| Sponge | EVA customized sponge, suitable for 95 guns |
| Sponge color | black |
| Specific application | 88 guns, up to 4 packs. |
| Features | Strong resistance to deformation/shock, low temperature resistance, weather resistance, waterproof, dustproof and antistatic |
| Box shaft | anti-falling long shaft hinge (stainless steel shaft) |
| Box lining | PU pre-segmented sponge/EVA engraved cotton/other materials customized |
| Breathing valve | waterproof, dustproof air pressure regulating valve |
| Lock | silent (standard) spring lock (aviation aluminum) |
| Handle | double-layer rubberized comfortable handle |
| Label slot | instrument label slot |
| Insert slot | used for instrument panel fixing |
| Strap/lock hole | Yes; can be customized to load the combination lock |
| Working temperature | -40°C to 90°C |
| Upper cover/casing | including fixing studs |
| Sealing ring | solid super-strength rebound, low temperature and waterproof |
| Box load | 3 tons |
Configuration Table
| 2 push-pull spring locks | 1 double-layer solid soft handle | 1 famous brand | 2 double-bearing silent load-bearing wheels |
| 1 waterproof and breathable valve | Strong and powerful whole hinge | 1 rubber waterproof sealing ring | 9 fixing posts and holes in the box |
| 2 strap holes/lock button holes | 1 set of PU pre-cut foam | EVA custom foam | 1 extended pull rod |
Product Testing Items
IP protection level test: ASTM IP67 (IP waterproof and dustproof protection level)
Dust spraying No dust ingress; box immersed in water, no water infiltration within the standard water pressure time
Low temperature drop test: FED-STD-101C (U.S. federal test method low temperature drop standard)
The box is equipped with 14KG weight, 0.64m height, free fall 26 times in all directions on the angular surface
Vibration/rain test: ASTMB4169, DC-18 (US federal test method vibration test standard)
Violent vibration at 5-50 Hz for 120 minutes, 3 axes, 40 minutes per axis, rainfall 100mm per hour, 40 minutes of rain on 6 surfaces
Drop hammer impact test: ATA300 (Air Transport Association standard drop hammer impact)
3.2cm in diameter, hemispherical top, 6KG in weight, 0.5m high impact
Waterproof test: MIL-STD-810F-512.4 (Federal testing standard immersion test)
Water depth 1m water pressure 1.5psi, duration 1 hour
Relative products
| Series - Injection Molded Plastic Small and Medium Safety Cases IP67 | |||||||
| Model | Outline(mm) | Inner(mm) | Cover/Box Depth(mm) | Color | Net Weight(kg) | Tie Bar | Wheel |
| M2100 | 395*299*148 | 334*237*132 | 32+100 | B/Y/G | 1.78 | N | N |
| M2200 | 413*328*168 | 381*267*152 | 48+104 | B/Y | 2.3 | N | N |
| M2360 | 464*358*208 | 432*297*193 | 48+145 | B/Y | 2.86 | N | N |
| M2400 | 493*395*185 | 462*334*170 | 48+122 | B/Y | 2.916 | N | N |
| M2500 | 587*358*221 | 525*297*192 | 48+144 | B/Y | 4.95 | Y | 2 |
| M2608 | 570*418*228 | 508*356*220 | 48+172 | B/G | 4 | N | N |
| M2620 | 570*418*285 | 508*356*254 | 48+206 | B/G | 5.2 | Y | 2 |
| M2720 | 624*498*285 | 563*437*254 | 48+206 | B | 7.5 | Y | 2 |
| M2750 | 624*498*353 | 563*437*323 | 48+275 | B | 8 | Y | 2 |
| M2950 | 802*522*298 | 741*461*267 | 78*189 | B | 8.9 | Y | 2 |
| RS Series Rotomolding Plastic Air Drop Cases | |||||||
| Model | Outline(mm) | Inner(mm) | Net Weight(kg) | Volume（L) | Wheel | Color | IP Grade |
| RS820 | 800*530*380 | 700*445*350 | 15 | 100 | Y | G | IP65 |
| RS830 | 800*600*560 | 730*530*450 | 18 | 170 | N | G | IP65 |
| RS860 | 961*697*398 | 871*615*355 | 20 | 190 | Y | G | IP65 |
| RS870 | 1100*530*360 | 1020*450*340 | 18 | 150 | Y | G | IP65 |
| RS880A | 1200*800*620 | 1100*730*600 | 33 | 480 | N | G | IP65 |
| RS880B | 1200*800*700 | 1100*730*680 | 37 | 550 | N | G | IP65 |
| RS890 | 2120*1070*625 | 2000*960*600 | 65 | 1150 | Y | G | IP65 |
| RUSeries Rotomolding Plastic Portable Shock-absorbing Rack Cases IP65 | |||||||
| Model | Outline(mm) | 19" Rack Installation Size | Cover/Box Depth(mm) | Shock-absorbing | Wheel | Tie Bar | Color |
| RU040 | 760*621*364 | 181*483*450 | 100+560 | 8/None | 2/4 | 4 | G |
| RU060 | 860*592*446 | 270.5*483*600 | 90+680 | 8/None | 2/4 | 4 | G |
| RU080 | 860*592*535 | 359.5*483*600 | 90+680 | 8/None | 2/4 | 4 | G |
| RU110 | 850*621*675 | 493*483*550 | 100+650 | 8/None | 2/4 | 4 | G |
