Product Description
PET Or PP Filament Geotextile
Product Introduction：
Polyester filament geotextile is made of PET or PP as raw material, and is produced by fusing spinning, air flow netting and needling consolidation. Filament geotextile has good mechanical function, good water permeability, corrosion resistance, anti-aging, isolation, filtration, drainage, protection, stability, reinforcement and other functions, can adapt to uneven base, can resist construction external filtration damage, creep becomes smaller, long-term load can still maintain the original function. Even in the environment of nearly 200℃ short-term exposure to its performance is almost unchanged, after a large number of tests and practice has proved that filament geotextile has a excellent natural soil, water and microorganisms long-term corrosion resistance.
Function And Use:
Water conservancy project: seawall, river dike, lake dike standard project; Reservoir strengthening project; Redation works; Flood prevention and rescue.
Highway, railway and airport engineering: soft foundation reinforcement treatment; Slope protection; Prevention reflective crack structure layer; Drainage system; Afforestation divider.
Electrical engineering: basic engineering of nuclear power plant; Thermal power ash dam project; Hydropower project.
For roads, railways, DAMS, coastal beaches and other projects reinforcement, reinforcement, filtration, isolation and protection, especially suitable for saline-alkali marsh, landfill.
Technical Indicators:
Technical specifications of filament spunbonded needled nonwoven geotextiles(GB/T17639-2008)
| Item | Unit | Technical data | |||||||
| specification | / | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 |
| Thickness | mm | 0.8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | 5.5 |
| ≥Breaking strength(MD/TD) | kN/m | ≥4.5 | ≥7.5 | ≥10 | ≥15 | ≥20 | ≥25 | ≥30 | ≥40 |
| Vertical and horizontal standard strength corresponds to elongation | % | 40~80 | |||||||
| CBR bursting strength | kN/m | ≥0.8 | ≥1.6 | ≥1.9 | ≥2.9 | ≥3.9 | ≥5.3 | ≥6.4 | ≥7.9 |
| Tear Strengh(MD/TD) | kN/m | ≥0.14 | ≥0.21 | ≥0.28 | ≥0.42 | ≥0.56 | ≥0.7 | ≥0.82 | ≥1.1 |
| Sieve size O90(O₉₅) | mm | 0.05~0.20 | |||||||
| Vertical permeability coeficent | cm/s | K×(10-1~10-3)： K=1.0~9.9 | |||||||
| Width deviation | % | -0.5 | |||||||
| Weight deviation | % | -5 | |||||||
Technical specifications of filament spunbonded needled nonwoven geotextiles(GB/T17639-2023):
| Item | Unit | Technical data | |||||||||
| Nominal strength(kN/m) | |||||||||||
| 6 | 9 | 12 | 18 | 24 | 30 | 36 | 48 | 54 | |||
| Longitudinal and transverse tensile strength | kN/m | ≥6 | ≥9 | ≥12 | ≥18 | ≥24 | ≥30 | ≥36 | ≥48 | ≥54 | |
| Elongation under maximum load in vertical and horizontal direction | % | 30~80 | |||||||||
| CBR bursting strength | kN/m | ≥0.9 | ≥1.6 | ≥1.9 | ≥2.9 | ≥3.9 | ≥5.3 | ≥6.4 | ≥7.9 | ≥8.5 | |
| Tear Strengh(MD/TD) | kN/m | ≥0.15 | ≥0.22 | ≥0.29 | ≥0.43 | ≥0.57 | ≥0.71 | ≥0.83 | ≥1.1 | ≥1.25 | |
| Sieve size 090 (O₉₅) | mm | 0.05~0.30 | |||||||||
| Vertical permeability coefficient | cm/s | K×(10⁻¹~10⁻³)： K=1.0~9.9 | |||||||||
| Width deviation | % | ≥-0.5 | |||||||||
| Weight deviation | % | ≥-5 | |||||||||
| Thicknes deviation rate | % | ≥-10 | |||||||||
| Thickness variation coefficient(CV) | % | ≤10 | |||||||||
| Vertical and horizontal breaking strength | kN | 0.3 | 0.5 | 0.7 | 1.1 | 1.4 | 1.9 | 2.4 | 3.0 | 3.5 | |
| Dynamic punch | Hole diameter | mm | ≤37 | ≤33 | ≤27 | ≤20 | ≤17 | ≤14 | ≤11 | ≤9 | ≤7 |
| Uv resistance(xenon arc lamp)° | Vertical and horizontal strength retention | % | ≥70 | ||||||||
| Uv resistance(fluorescent UVlamp)a | Vertical and horizontal strength retention | % | ≥80 | ||||||||
