Nylon Mooring Tails
Product Introduction:
When using wire ropes for ship mooring, the inherent rigidity of the steel wire lacks the necessary elasticity to handle sudden shock loads. To address this, a synthetic fiber mooring tail is essential. By attaching a Nylon Mooring Tail to the wire rope, the assembly gains crucial elasticity to absorb instantaneous impacts, allowing it to adapt seamlessly to varying wind, wave, and current conditions. This configuration significantly equalizes the load distribution across the entire mooring line, preventing premature failure and enhancing overall operational safety.
Key Features:
1.Material: High-quality Nylon (Polyamide), known for excellent elasticity and energy absorption.
2.Construction: Available in 8-strand or 12-strand braided construction for superior strength and durability.
3.Exceptional Strength: Engineered for high performance, with a Minimum Breaking Load (MBL) rated at 140% against the MBL of the connecting Wire Rope (MBL ranges from 40 Tons to 230 Tons).
4.End Fittings: Both ends are professionally spliced (Both end type) for secure and reliable connections.
5.Shock Absorption: Provides the necessary stretch to dampen sudden forces, ensuring smoother and more uniform tension on the mooring system.
6.Standard Dimensions: Standard length is 11 meters, with circumferences ranging from 6" (48mm dia.) to 15" (120mm dia.). Weights range from 25 kg/coil to 160 kg/coil.
Parameter Table:
| CIR | DIA | Length. (M) | Construction | MBL(Ton) | Type | Weight(kg/coil) | Note |
| 6" | 48mm | 11 | 8 or 12 strand | 40 | Both end | 25 | 140%against MBL of Wire Rope |
| 7" | 56mm | 11 | 8 or 12 strand | 55 | Both end | 35 | 140%against MBL of Wire Rope |
| 8" | 64mm | 11 | 8 or 12 strand | 70 | Both end | 45 | 140%against MBL of Wire Rope |
| 9” | 72mm | 11 | 8 or 12 strand | 90 | Both end | 60 | 140%against MBL of Wire Rope |
| 10” | 80mm | 11 | 8 or 12 strand | 110 | Both end | 75 | 140%against MBL of Wire Rope |
| 11” | 88mm | 11 | 8 or 12 strand | 130 | Both end | 90 | 140%against MBL of Wire Rope |
| 12" | 96mm | 11 | 8 or 12 strand | 150 | Both end | 105 | 140%against MBL of Wire Rope |
| 13” | 104mm | 11 | 8 or 12 strand | 175 | Both end | 120 | 140%against MBL of Wire Rope |
| 14" | 112mm | 11 | 8 or 12 strand | 200 | Both end | 140 | 140%against MBL of Wire Rope |
| 15” | 120mm | 11 | 8 or 12 strand | 230 | Both end | 160 | 140%against MBL of Wire Rope |
Applications:
Specifically designed for marine and offshore applications where steel wire ropes are used for mooring. Ideal for vessels operating in dynamic environments, docks, and terminals facing varying wind and current conditions.
Customization & Compliance:
*Customization: While standard sizes are available, custom colors, lengths, diameters, and configurations can be manufactured upon request to meet specific operational requirements.
*Certifications:Our ropes are manufactured under strict quality control systems and can be supplied with classification society approval certificates from leading international bodies such as DNV, ABS, LR, BV, and CCS upon request. These certifications ensure full compliance with international maritime regulations, port state controls, and insurance underwriter requirements, giving you complete operational peace of mind.
