Marine Steel Visor

Marine Steel Visor

Modle	Suitable clear light of side scuttle	R	Spread length	Structure		Weight(Kg)				Suitable scope
				A1、A2	A3、A4	A1	A2	A3	A4
A1、A3	Φ200	185	517	Round steel d 25	Angle steel L25*25*3	1.99	_	0.58	_	Bolted type side scuttle
	Φ250	210	583			2.24	_	0.66	_
	Φ300	235	648			2.5	_	0.73	_
	Φ350	260	713			2.75	_	0.8	_
	Φ400	285	779			3	_	0.88	_
	Φ450	310	844			3.25	_	0.95	_
A2、A4	Φ200	135	386			_	1.49	_	0.43	Welding type side scuttle
	Φ250	163	459			_	1.77	_	0.56
	Φ300	190	530			_	2.04	_	0.6
	Φ350	215	596			_	2.3	_	0.67
	Φ400	240	661			_	2.55	_	0.74
	Φ450	265	726			_	2.8	_	0.82

Model	Suitable clear light of rectangular window	B		B1	R	h	Angle steel specification	Weight(Kg)			Suitable scope
		Model B	Model C					B1	B2	C
B1、C1	300*425	480	240	140	120	10	L25*25*3	0.62	_	1.124 (kg/m)	Inward opened bolted mount type  rectangular window
	355*500	535	268	140	120			0.69	_
	400*560	580	290	140	120			0.74	_
	450*630	630	315	190	170			0.82	_
	500*710	680	340	190	170			0.88	_
	560*800	740	370	190	170			0.95	_
	900*630	1080	_	190	170			1.38	_
	1000*710	1180	_	190	170			1.5	_
	1100*800	1280	_	190	170			1.62	_
B2、C2	300*425	400	200	100	80			_	0.52		Inward opened weldingmount type  rectangular window
	355*500	455	228	100	80			_	0.6
	400*560	500	250	100	80			_	0.66
	450*630	550	275	150	130			_	0.72
	500*710	600	300	150	130			_	0.78
	560*800	660	330	150	130			_	0.86
	900*630	1000	_	150	130			_	1.28
	1000*710	1100	_	150	130			_	1.4
	1100*800	1200	_	150	130			_	1.53
