Product Description
| Model | Nominal size | Window frame size | Cut-out size | Glass thickness | Weight(Kg) | ||||||
| W*H | W1*H1 | W2*H2 | W3*H3 | R3 | BH,WH | BN,WN | BH | BN | WH | WN | |
| BN BH WN WH | 800*630 | 848*678 | 930*760 | 852*682 | 144 | 12 | 15 | 28.5 | 28.9 | 44.3 | 44.8 |
| 800*710 | 848*758 | 930*840 | 852*762 | 12 | 15 | 31.1 | 31.7 | 47.2 | 47.8 | ||
| 900*630 | 948*678 | 1030*760 | 952*682 | 12 | 17 | 31.2 | 33 | 48.1 | 49.9 | ||
| 900*710 | 948*758 | 1030*840 | 952*762 | 12 | 17 | 33.9 | 35.9 | 51.5 | 53.5 | ||
| 900*800 | 948*848 | 1090*930 | 952*852 | 12 | 17 | 36.9 | 39.1 | 55.4 | 57.6 | ||
| 1200*630 | 1248*678 | 1330*760 | 1252*682 | 15 | 20 | 44.6 | 47 | 63.9 | 66.3 | ||
| 1200*710 | 1248*758 | 1330*840 | 1252*762 | 15 | 20 | 50.9 | 53.6 | 71.6 | 74.2 | ||
| 1200*800 | 1248*848 | 1330*930 | 1252*852 | 15 | 20 | 55.6 | 58.6 | 77.2 | 80.2 | ||
| 1500*710 | 1548*758 | 1630*840 | 1552*762 | 15 | 20 | 61.1 | 64.4 | 84.8 | 88.1 | ||
| 1500*800 | 1548*848 | 1630*930 | 1552*852 | 15 | 20 | 66.2 | 69.9 | 91.4 | 95.1 | ||
| 1800*710 | 1848*758 | 1930*840 | 1852*762 | 15 | 20 | 71.3 | 75.3 | 98.1 | 102.1 | ||
| 1800*800 | 1848*848 | 1930*930 | 1852*852 | 15 | 20 | 77.4 | 81.8 | 105.3 | 110.4 | ||
| 1800*900 | 1848*948 | 1930*1030 | 1852*952 | 15 | 20 | 82.5 | 87.5 | 114.1 | 119.2 | ||
| Power system | Overheated protection device | Minimum power load (W/dm2) | Power system | Overheated protection device | Minimum power load (W/dm2) | ||||||||
| Power | Voltage | Frequency | Code | Power | Voltage | Frequency | Code | ||||||
| 7 | 12 | 17 | 7 | 12 | 17 | ||||||||
| DC | 24 | __ | G | 7G01 | 12G01 | 17G01 | AC Three phase | 115 | 50 | G | 7G31 | 12G31 | 17G31 |
| S | 7S01 | 12S01 | 17S01 | S | 7S31 | 12S31 | 17S31 | ||||||
| 110 | __ | G | 7G02 | 12G02 | 17G02 | 60 | G | 7G32 | 12G32 | 17G32 | |||
| S | 7S02 | 12S02 | 17S02 | S | 7S32 | 12S32 | 17S32 | ||||||
| 220 | __ | G | 7G03 | 12G03 | 17G03 | 220 | 50 | G | 7G33 | 12G33 | 17G33 | ||
| S | 7S03 | 12S03 | 17S03 | S | 7S33 | 12S33 | 17S33 | ||||||
| AC Single phase | 115 | 50 | G | 7G11 | 12G11 | 17G11 | 60 | G | 7G34 | 12G34 | 17G34 | ||
| S | 7S11 | 12S11 | 17S11 | S | 7S34 | 12S34 | 17S34 | ||||||
| 60 | G | 7G12 | 12G12 | 17G12 | 220~380 | 50 | G | 7G35 | 12G35 | 17G35 | |||
| S | 7S12 | 12S12 | 17S12 | S | 7S35 | 12S35 | 17S35 | ||||||
| 220 | 50 | G | 7G13 | 12G13 | 17G13 | 60 | G | 7G36 | 12G36 | 17G36 | |||
| S | 7S13 | 12S13 | 17S13 | S | 7S36 | 12S36 | 17S36 | ||||||
| 60 | G | 7G14 | 12G14 | 17G14 | 440 | 50 | G | 7G37 | 12G37 | 17G37 | |||
| S | 7S14 | 12S14 | 17S14 | S | 7S37 | 12S37 | 17S37 | ||||||
| Overheat protection device G means two pieces or more combined adjustment.S means single piece adjustment | 60 | G | 7G38 | 12G38 | 17G38 | ||||||||
| S | 7S38 | 12S38 | 17S38 | ||||||||||
