Product Description
JA Type Rubber Shock Absorber
Product introduction
The JA damping rubber shock absorber is made up of upper and lower shells and rubber damping layer. It is suitable for vibration and shock isolation of all kinds of machinery with 1500 revolutions and above. The natural frequency is 10Hz under the rated load. The structure is simple, the installation and update is convenient, and the use is safe and reliable. Various types of installation are suitable for a variety of installation forms, such as flat, side and side hanging. The lateral stiffness is higher than the longitudinal stiffness, and the lateral stability is better when it is flat.
The JA type rubber shock absorber can achieve high damping effect on axial pressure and lateral pressure, especially for generators, engines and systems. The damping effect is very good, and the application range is about 25Hz (1.500 RPM).
The internal rubber and iron piece completely glued, can provide the best damping effect, and also comes with safety lock parts, to ensure safety.
JA rubber shock absorber shows that
The internal rubber and iron completely glued together with a safety lock, in addition to the safety of parts.
The shock absorber can achieve a high shock absorption effect in the axial and lateral pressure.
It is suitable for all kinds of generator, water pump, fan, air conditioning unit and so on.
Performance parameters
| Model | Rubbor hardnoss (IRHD) | A | B | P | F*M | CF | L | S | Avorogokoad(Kg/mm) | Maximum load (Kg) | Maximum compresslon(mm) |
| JA633008W | 45 | 63 | 30 | M8 | 9*14 | 89 | 110 | 2.5 | 70 | 140 | 2 |
| JA633008M | 60 | 63 | 30 | M8 | 9*14 | 89 | 110 | 2.5 | 120 | 240 | 2 |
| JA633010W | 45 | 63 | 30 | M10 | 9*14 | 89 | 110 | 2.5 | 70 | 140 | 2 |
| JA633010M | 60 | 63 | 30 | M10 | 9*14 | 89 | 110 | 2.5 | 120 | 240 | 2 |
| JA783010W | 45 | 78 | 30 | M10 | 9*12 | 110 | 135 | 2.5 | 47 | 108 | 2.3 |
| JA783010M | 60 | 78 | 30 | M10 | 9*12 | 110 | 135 | 2.5 | 116 | 267 | 2.3 |
| JA833010W | 45 | 83 | 30 | M10 | 9*13 | 110 | 135 | 3 | 65 | 195 | 3 |
| JA833010M | 60 | 83 | 30 | M10 | 9*13 | 110 | 135 | 3 | 98 | 294 | 3 |
| JA833512W | 45 | 83 | 35 | M12 | 9*13 | 110 | 135 | 3 | 65 | 195 | 3 |
| JA833512M | 60 | 83 | 35 | M12 | 9*13 | 110 | 135 | 3 | 98 | 294 | 3 |
| JA923512W | 45 | 92 | 35 | M12 | 10*15 | 124 | 150 | 3 | 50 | 175 | 3.5 |
| JA923512M | 60 | 92 | 35 | M12 | 10*15 | 124 | 150 | 3 | 90 | 315 | 3.5 |
| JA1063812W | 45 | 106 | 38 | M12 | 13*19 | 143 | 175 | 4 | 70 | 252 | 3.6 |
| JA1063812M | 60 | 106 | 38 | M12 | 13*19 | 143 | 175 | 4 | 150 | 450 | 3 |
| JA1254316W | 45 | 125 | 43 | M16 | 14.5*20 | 156 | 192 | 4 | 88 | 352 | 4 |
| JA1254316M | 60 | 125 | 43 | M16 | 14.5*20 | 156 | 192 | 4 | 185 | 740 | 4 |
| JA1505016W | 45 | 150 | 50 | M16 | 14*18 | 182 | 218 | 4 | 120 | 720 | 6 |
| JA1505016M | 60 | 150 | 50 | M16 | 14*18 | 182 | 218 | 4 | 220 | 1320 | 6 |
| JA1505020W | 45 | 150 | 50 | M20 | 14*18 | 182 | 218 | 4 | 120 | 720 | 6 |
| JA1505020M | 60 | 150 | 50 | M20 | 14*18 | 182 | 218 | 4 | 220 | 1320 | 6 |
