Product Description
4500*9000 Hydro-Pneumatic Fenders
Product introduction
Hydro-Pneumatic Fenders represent the pinnacle of marine fender technology, engineered to protect high-value vessels and offshore structures in the most demanding conditions. Unlike conventional rubber fenders, our advanced system combines water and compressed air to deliver unparalleled energy absorption and reaction force control.
Sizes And Performance
| DIAMETER X LENGTH (mm x mm) | INITIAL INTERNAL PRESSURE (kPa) | SHIP RADIUS (mm) | WATER RATIO (%) | GUARANTEED ENERGY ABSORPTION (kJ) | REACTION FORCE AT GEA (kN) | HULL PRESSURE AT GEA (kPa) | DEFLECTION AT GEA (%) |
| 1500x6100 | 50 | 3000 | 60% | 131 | 562 | 140 | 51% |
| 80 | 186 | 754 | 188 | ||||
| 1700x7200 | 50 | 4000 | 65% | 167 | 682 | 137 | 47% |
| 80 | 239 | 918 | 184 | ||||
| 2000x6000 | 50 | 4000 | 70% | 135 | 544 | 131 | 41% |
| 80 | 194 | 736 | 177 | ||||
| 2500×5500 | 50 | 4500 | 65% | 225 | 769 | 135 | 41% |
| 80 | 322 | 1035 | 182 | ||||
| 2500x7700 | 50 | 4500 | 70% | 326 | 1016 | 136 | 41% |
| 80 | 470 | 1368 | 183 | ||||
| 3300x6500 | 50 | 4500 | 75% | 307 | 887 | 127 | 35% |
| 80 | 442 | 1203 | 173 | ||||
| 3300x10600 | 50 | 5000 | 65% | 1003 | 2137 | 142 | 47% |
| 80 | 1429 | 2863 | 190 | ||||
| 4500×9000 | 50 | 5000 | 60% | 1439 | 2401 | 138 | 46% |
| 80 | 2059 | 3228 | 185 | ||||
| 4500x12000 | 50 | 6000 | 65% | 1977 | 3198 | 141 | 46% |
| 80 | 2819 | 4277 | 189 |
The table above is to be used for reference only.The required energy absorption and reaction forces can be manufactured to suit your application.
Due to the very specialist nature of Hydro pneumatic fenders,it is strongly advised that a detailed study be carried out for each case.
Key Advantages & Features
Superior Energy Absorption
Low and Controllable Reaction Force
Consistent Performance in All Tides
Customizable & Scalable
Durability and Low Maintenance
