40T Angular close top Triplex Type Electro-hydraulic Shark Jaw

Brand: Deyuan Marine
Drive: Electro-hydraulic
Bollard pull: 40~200 ton
Holding capacity: 100~700 ton
Power required: 15~37KW
Shark Jaw type: Triplex Type
Certificate: ABS,DNV,RINA,CCS
Availability:

Product Description

Triplex Type Shark Jaw Features :
a) Capacity:100 to 700 Tonnes SWL.
b) Inline vertical type Towing Pin.
c) Angular close top type Towing Pin.
d) Combine Modular type towing Pin& shark Jaw.
Shark Jaw Model Towing Pin Model Bollard Pull (ton) Holding Capacity (ton) Power Reqired (kw)
SJ-100 TP-100 40 100 15
SJ-200 TP-200 60 200 22
SJ-300 TP-300 85 300 22
SJ-400 TP-400 120 400 30
SJ-500 TP-500 150 500 30
SJ-700 TP-700 200 700 37

More triplex type shark jaw can be offered,pls contact us for more details.
