21KN Single Arm Slewing Life Raft Davit Crane For Rescue

Brand:Deyuan Marine
Product Name:Single Arm Liferaft Davit
Material:Cast Steel
Type:For Liferaft
Certificate:CCS ,EC,ABS ,BV etc
Payment:T/T,L/C ,Paypal
Package:Standard package
Delivery time:10-30 days
  • Deyuan Marine

  • Item: Single Arm Slewing Davit
  • Working Load : 14KN,21KN,23KN
  • Certificate: CCS,ABS,RINA,DNV,BV,LR etc
  • Application: lifting&lowering Rescue Boat/Liferaft .
  • Warranty : 1year
  • Payment terms: TT,LC,Paypal,Credit card,western union

Product Description

21KN Single Arm Slewing Life Raft Davit Crane For Rescue

Single Arm Slewing Davit is used for hoisting the special equipment of the life raft. Single Arm Slewing Boat Davit is divided into two kinds of models to meet the ship's side layout needs.

When the ship heeling 20 ° or trim 10 °.The Liferaft Davit can work normally. The Liferaft Handling Cranes conforms to the requirements of "amendments to the international convention for the safety of human life in 1974" (1983), msc.47 (66)& msc.216 (82) and ship registration.

Below is the major parameter of Single Arm Davit

Single Arm Rescue Crane SWL:21KN

Hoisting load:21KN

Lifting speed:≥18m/min

Full load drop speed:45~55m/min

Capacity of drum:25m

Diameter of wire rope:16mm

Turning radius:5.4m (designed as required)

Angle: roll list 20 ° or less

Trim the trim 10 ° or less

SOLAS Single Arm Rescue Davit with good working performance and high quality .All them Slewing Single Arm Davit with 12 months quality guarantee and professional after sales service .

If you need more information of 21KN Liferaft Davit please contact us .Below is the data sheet of 21KN Single Arm Liferaft Davit for your information .

Model Max. Safety working load Hoisting load Hoisting speed Landing speed Rope capacity of the reel Rotation Radius
SARC21 21KN 14KN ≥18m/min 40-60m/min 30m 3600-4500mm
SA23-1 23KN 14KN 3600-5400mm
SA23-2 23KN 18KN 3600-5000mm

Crane main Technical data:

Max. Hoisting load Rope capacity of the reel Max. Rotation Angle Landing speed Rotation Radius
30KN 30m ≤330° 11-15 m/min 4100-5000mm
15KN 4100-7300mm
30KN 4100-5500mm
