Marine Electro-Hydraulic Valve Remote Control Device
Product Introduction:
Electro-hydraulic valve remote control device consists of control console, electro-hydraulic actuator, butterfly valve and manual hydraulic emergent pump station. The device has advantage of hydraulic and electric remote control device; it has characteristics of compact structure, steady act, low consumption, low noise, and easy maintenance etc. It’s used for remote control piping valve's start & stop of all kinds of ships, such as oil tanker, chemical vessel, petroleum flat and float dock etc.
Main Technical Specification:
| Model | YFK-06DY |
| Power supply | AC 220V/50(60)Hz |
| Working temp. | -10~55℃ |
| Relative humidity | ≤95% |
| Working pressure | 11MPa |
| Protection | IP22 (control console);IP56(Electro-hydraulic valve) |
General Diagram:
