Sacrificial Anodes
A ship is continuously in contact with water and moisture laden winds which makes it highly susceptible to corrosion.
Anode is the main component of galvanic cathodi protection system used to protect buried or submerged metal structures from corrosion.
Three most active materials used in sacrificial anodes are zinc, aluminum and magnesium.Zinc and aluminium are generally used in salt water,widely used for hulls of ships and boats,offshore pipelines and production platforms,on small boat propellers and rudders and for the internal surface of storage tanks.
Deyuan marine provide all sizes anodes in different shapes,our main products for anodes is zinc anode,aluminum anodes,magnesium anodes,pls feel free to contact our sales team for more details.
Aluminum Anode for storage tank | Model | Size/㎜ | Weight/ kg |
| A×（B1+B2）×C |
|
| AC-1 | 750×（115+135）×130 | 35 |
| AC-2 | 500×（115+135）×130 | 23 |
| AC-3 | 500×（105+135）×100 | 16 |
| AC-4 | 300×（105+135）×100 | 10 |
Aluminum Anode for Harbor and marine Engineering Facilities | model | size/mm | weight/ kg |
| A×（B1+B2）×C |
|
| AI-1 | 2300×（220+240）×230 | 310 |
| AI-2 | 1600×（200+210）×220 | 190 |
| AI-3 | 1500×（170+200）×180 | 130 |
| AI-4 | 900×（150+170）×160 | 58 |
| AI-5 | 1500×（148+178）×170 | 120 |
| AI-6 | 850×（180+220）×180 | 85 |
| AI-7 | 800×（200+280）×150 | 80 |
| AI-8 | 700×（160+220）×180 | 72.5 |
| AI-9 | 1250×（115+135）×130 | 56 |
| AI-10 | 1000×（115+135）×130 | 46 |
| AI-11 | 750×（115+135）×130 | 35 |
| AI-12 | 500×（115+135）×130 | 23 |
Aluminum Anode for ballast water tank | Type | Size/mm | Weight/ kg |
| A×（B1+B2）×C |
|
| AT-1 | 500×（115+135）×130 | 23 |
| AT-2 | 1500×（65+75）×70 | 21.5 |
| AT-3 | 500×（110+130）×120 | 20 |
| AT-4 | 1000×（58.5+78.5）×68 | 13.2 |
| AT-5 | 800×（56+74）×65 | 10 |
| AT-6 | 1150×（48+54）×51 | 9 |
| AT-7 | 250×（80+100）×85 | 5 |
| AT-8 | 200×（70+90）×70 | 3 |
Aluminum Anode for Seawater Cooling System | model | size/mm | weight/ kg |
| A×（B1+B2）×C |
|
| AE-1 | 1200×（200+280）×150 | 120 |
| AE-2 | 800×（200+280）×150 | 80 |
| AE-3 | 1000×（115+135）×130 | 46 |
| AE-4 | 500×（115+135）×130 | 23 |
| AE-5 | 1000×（80+100）×80 | 20 |
| AE-6 | 500×（105+135）×100 | 16 |
| AE-7 | 500×（80+100）×80 | 10 |
| AE-8 | 400×（110+120）×50 | 7 |
| AE-9 | 300×（140+160）×40 | 5 |
| AE-10 | 200×（90+110）×40 | 3 |
| AE-11 | 300×50 disc type | 11.5 |
| AE-12 | 360×40 disc type | 9 |
| AE-13 | 300×40 disc type | 7.5 |
| AE-14 | 200×50 disc type | 4 |
| AE-15 | 180×50 disc type | 3.5 |
| AE-16 | 120×100 disc type | 2.5 |
Aluminum Anode for ship hull | Model | Size/㎜ | Weight/ kg |
| A×B×C |
|
| AH-1 | 800×140×60 | 17 |
| AH-2 | 800×140×50 | 15 |
| AH-3 | 800×140×40 | 12 |
| AH-4 | 600×120×50 | 10 |
| AH-5 | 400×120×50 | 6.5 |
| AH-6 | 500×100×40 | 5.5 |
| AH-7 | 400×100×40 | 4.5 |
| AH-8 | 300×100×40 | 3.5 |
| AH-9 | 250×100×40 | 2.5 |
| AH-10 | 180×70×35 | 1.2 |
| AH-11 | 300×150×50 | 5.8 |
| AH-12 | 300×150×40 | 4.6 |
| AH-13 | 300×150×40 | 4.8 |
