Wall Mounting Waterproof Light & Electronic Bell

YLX120-F-II Waterproof Light & Electronic Bell

Product Introduction

The Marine Waterproof Combined Light & Electronic Bell is a versatile, multi-signal alarm device engineered for critical marine applications. Designed for high-visibility and high-audibility alerting in harsh maritime environments, this unit combines a powerful rotating/strobe light with an electronic sounder in a single, compact housing. It serves as a highly effective alarm indicator for hospital emergency systems, machinery alarms, general alerts, and muster stations, providing simultaneous visual and audible notification essential for crew safety and operational awareness.

Technical Features & Design Specifications

The light module utilizes high-intensity LEDs available in red, amber, blue, or clear/white configurations, with multiple flash patterns (steady, rotating, strobe) and adjustable intensity up to 10,000 candela. The electronic bell sounder produces distinctive, penetrating tones up to 110dB(A) at 1 meter, with selectable frequencies and sound patterns compliant with marine signal regulations.

System Integration & Performance Advantages

The unit operates on standard 24V DC or 110/220V AC shipboard power systems with universal voltage compatibility (20-265V AC/DC). It features independent or synchronized light-sound activation modes, allowing flexible configuration for different alarm scenarios. The advanced electronics include built-in surge protection, polarity reversal protection, and thermal overload safeguards. Installation is simplified through a universal mounting base with 360-degree rotation capability, conduit entries, and clearly marked terminal blocks. The device is designed for minimal maintenance with corrosion-resistant fasteners and field-replaceable components.

Certification & Operational Reliability

Fully compliant with SOLAS, IMO, and major classification society requirements for marine alarm and signal devices, this combined unit offers exceptional reliability in extreme conditions (-40°C to +70°C operating temperature). The optional configurations include explosion-proof versions for hazardous areas, synchronized multi-unit systems for large spaces, and network-enabled models for integrated monitoring. Its rugged design withstands constant vibration, salt spray, UV exposure, and mechanical impact, making it an ideal solution for external decks, engine rooms, and other challenging marine locations where clear, unmistakable signaling is essential for safety and operational efficiency.

Drawing

Technical Data

Hospital Call Alarm System

Hospital Call Alarm System Connection Diagram
