Product Description
Two Drum Single Gypsy Ship Hydraulic Anchor Windlass
Hydraulic drived Anchor Windlass can fit the gypsy suitable for anchor chain with diameter from 16mm to 97mm;
One Gypsy and double drum can operate seperately with cluthes,very easy to control anchoring the anchor or rolling rope.
The ship anchor windlass is drove by hydraulic power pack, and electric drived type is also available, power supply will be mattched with your require.
We can offer SOLAS Shipping certificate,such as ABS, BV, NK, DNV, GL, LR, RINA, CCS ZC, ZY etc.,
Type | Chain Drum | Hawser Drum | Motor Power | ||||
Chain Dia | Load | Speed | Load | Speed | Rope Size | (kW) | |
(mm) | (kN) | (m/min) | (kN) | (m/min) | (mm×m) | ||
YM2F40 | 40 | 68 | 12 | 50 | ≥15 | 65×150 | 30 |
YM2F42 | 42 | 75 | 12 | 50 | ≥15 | 65×150 | 30 |
YM2F44 | 44 | 82.3 | 12 | 50 | ≥15 | 65×150 | 30 |
YM2F46 | 46 | 89.9 | 12 | 50 | ≥15 | 80×150 | 37 |
YM2F48 | 48 | 97.9 | 12 | 50 | ≥15 | 80×150 | 37 |
YM2F50 | 50 | 103.3 | 12 | 50 | ≥15 | 80×150 | 37 |
YM2F52 | 52 | 114.9 | 12 | 80 | ≥15 | 80×180 | 45 |
YM2F54 | 54 | 123.9 | 12 | 80 | ≥15 | 80×180 | 45 |
YM2F56 | 56 | 133.3 | 12 | 80 | ≥15 | 80×180 | 55 |
YM2F58 | 58 | 143 | 12 | 80 | ≥15 | 80×200 | 55 |
YM2F60 | 60 | 153 | 12 | 80 | ≥15 | 80×200 | 55 |
YM2F36/3 | 36 | 61.6 | 12 | 50 | ≥15 | 65×150 | 30 |
YM2F38/3 | 38 | 68.9 | 12 | 50 | ≥15 | 65×150 | 30 |
YM2F40/3 | 40 | 76 | 12 | 50 | ≥15 | 65×150 | 30 |
YM2F42/3 | 42 | 83.8 | 12 | 50 | ≥15 | 80×150 | 37 |
YM2F44/3 | 44 | 92 | 12 | 50 | ≥15 | 80×150 | 37 |
YM2F46/3 | 46 | 100.5 | 12 | 50 | ≥15 | 80×150 | 37 |
YM2F48/3 | 48 | 109.4 | 12 | 100 | ≥15 | 80×180 | 45 |
YM2F50/3 | 50 | 118.8 | 12 | 100 | ≥15 | 80×180 | 45 |
YM2F52/3 | 52 | 128.4 | 12 | 100 | ≥15 | 80×180 | 55 |
YM2F54/3 | 54 | 138.5 | 12 | 80 | ≥15 | 80×200 | 55 |
YM2F56/3 | 56 | 149 | 12 | 80 | ≥15 | 80×200 | 55 |
More two drum type hydraulic single anchor windlass can be offered,pls contact us for more details and professional service.
