Product Description
DA Type Rubber Fender D Type Rubber Fenders with Good price
Type super arch (DA) rubber fender is one of the most widely used fender varieties. It produces unit weight energy absorption in the compression type fender after super drum fender, 3.5 times higher than the cylinder type fender and 2.3 times higher than the type D fender and save material.
DA Type also called as super Arch rubber fender,it has the better stability and stronger attachment to the supporting structure than the traditional arch rubber fenders.
The DA Type Super Arch Marine Rubber Fender, which is commomest used for the quay and dock for the protection of the boats and ships, is tough and reliable, simple and long lasting, providing trouble-free service for a wide variety of berthing even under the most severe conditions. Super Arch rubber fender has the better stability and stronger attachment to the supporting structure than the traditional arch rubber fenders.
Features
1. High energy absorption and low reaction force.
It is a new generation of V fenders , with 3-3.5%increased energy absorption. That is: Application of the super arch fender can reduce product height and save project cost. The following is the performance comparison of these two kinds of fenders.
2. Reasonable Structure and long service time
The special structure design of the fender greatly improved the stress concentration under compression deflection which prolong its service time a lot.
3. Can be installed firmly and replaced easily
Because the fender has the same bolt pitch as the V type, it can be easily used to replace the V type fender so as to obtain higher performance.
Specification | Dimensions | ||||||||||||||
H | L | L1 | a | Q | n | C | B | A | b | h | c | d | e | f | |
200×1000 | 200 | 1000 | 1100 | 120 | 860 | 1 | 130 | 320 | 400 | 128 | 30 | 58 | 105 | 29 | 75 |
200×1500 | 200 | 1500 | 1600 | 120 | 680 | 2 | |||||||||
200×2000 | 200 | 2000 | 2100 | 120 | 620 | 3 | |||||||||
200×2500 | 200 | 2500 | 2600 | 122.5 | 785 | 3 | |||||||||
200×3000 | 200 | 3000 | 3100 | 120 | 715 | 4 | |||||||||
200×3500 | 200 | 3500 | 3600 | 120 | 672 | 5 | |||||||||
250×1000 | 250 | 1000 | 1125 | 130 | 865 | 1 | 164 | 410 | 500 | 160 | 64 | 125 | 32 | 90 | |
250×1500 | 250 | 1500 | 1625 | 132.5 | 680 | 2 | |||||||||
250×2000 | 250 | 2000 | 2125 | 132.5 | 620 | 3 | |||||||||
250×2500 | 250 | 2500 | 2625 | 127.5 | 790 | 3 | |||||||||
250×3000 | 250 | 3000 | 3125 | 132.5 | 715 | 4 | |||||||||
250×3500 | 250 | 3500 | 3625 | 130 | 673 | 5 | |||||||||
300×1000 | 300 | 1000 | 1150 | 140 | 870 | 1 | 225 | 490 | 600 | 195 | 33 | 70 | 140 | 35 | 105 |
300×1500 | 300 | 1500 | 16250 | 140 | 685 | 2 | |||||||||
300×2000 | 300 | 2000 | 2150 | 137.5 | 625 | 3 | |||||||||
300×2500 | 300 | 2500 | 2650 | 140 | 790 | 3 | |||||||||
300×3000 | 300 | 3000 | 3150 | 145 | 715 | 4 | |||||||||
300×3500 | 300 | 3500 | 3650 | 140 | 674 | 5 |
