Marine Ship Single-leaf Aluminium Door For Glass Cabin

Origin: Made in China
Type: Aluminium Door
Clear size: 600*1600mm
Location: Glass Cabin
Application: Boat, ship
Certificate: CCS, BV, NK, DNV etc
Delivery time: 10-30days
Packing: Export package
Payment terms: TT, western union, paypal etc
Brand: Deyuan Marine
Availability:

Product Description

Marine Ship Single-leaf Aluminium Door For Glass Cabin


Marine single leaf aluminium door is widely use on ship, boat cabins, above type use at glass cabin, with standard celar size from 600*1600mm to 800*1750mm, other size can also customized as per customer required.


This kind of ship single-leaf aluminium oor opening direction as rule GB 11874-89


All our aluminium doors carry out below requirements before delivery:

1. All doors carry out strength test, make sure they make meet the strength requirement.

2. All doors carry out Opening and closing test, make sure the flexibility of all doors.

3. The surface of doors don’t have any flaw like scratch and concave-convex

4. When close or open the door, the door frame aren’t out of shape and become less crowded

5. The alloy aluminum will carry out anodic oxidation treatment. And the hollow door will do coating processing.



Model Clear Size
(mm)
Door Frame Size
(mm)
Cut-out Size
(mm)

WXh  W1Xh1 W2Xh2
QLM-346

QLM-347

QLM-348
600X1600 706X1706 680X1680
650X1650 756X1756 730X1730
700X1700 806X1806 780X1780
700X1750 806X1856 780X1830
750X1750 856X1856 830X1830
800X1750 906X1856 880X1830


Model Clear Size
(mm)
Door Frame Size
(mm)
Cut-out Size
(mm)

WXh  W1Xh1 W2Xh2 R
QLR-346

QLR-347

QLR-348
600X1600 706X1706 680X1680 80
650X1650 756X1756 730X1730
700X1700 806X1806 780X1780
700X1750 806X1856 780X1830
750X1750 856X1856 830X1830
800X1750 906X1856 880X1830


Marked sample: Single-leaf square-corner aliminium glass cabin door  which clear size 600X1600.
Marked as: SINGLE-LEAF ALUMINIUM GLASS CABIN DOOR  600X1600   QLM-346
