Product Description
LST-PAU Desktop Welding Machine
Product Introduction
The welding machine adopts a stepless pressure-adjusting pressing wheel system and an intelligent operation control panel, and is widely used in the folding and stringing welding of advertising printing cloth and industrial tarpaulin. The operation is simple, the welding speed is fast and the welding effect is good. It can be quickly installed on the sitting or vertical work surface, saving the preparation work and supplementary welding time of the handheld welding equipment.
Product Parameters
| Model | LST-UME | LST-MAT1 | LST-MAT2 | LST-PAU |
| Rated Voltage | 120/230V | 230V | 230V | 120V/230V |
| Frequency | 50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60Hz |
| Rated Power | 2200/2800 W | 4200 W | 4200 W | 2300/3600 W |
| Welding Speed | 1.5-10.0 m/min | 1.0-10.0 m/min | 1.0-10.0 m/min | 1.0-12.0 m/min |
| Welding Temperature | 50～620℃ | 50～620℃ | 50～620℃ | 50～620℃ |
| Seam Width | 20/30/40 mm | 40/50/80 mm | 40/50/80 mm | 20/30/40 mm |
| Net Weight | 12.5 Kg | 22.0 Kg | 24.0 Kg | 20.0 Kg |
| Motor | Brush | Brush | Brush | Brushless |
| Certificate | CE | CE | CE | CE |
| Warranty | One year | One year | One year | One year |
Advantage
1. Folding guide
Three welding applications can be realized: closed hemming (20/30/40mm optional), rope hemming, and open hemming up to 180mm.
2. Intelligent control system
The intelligent digital control system is simple, intuitive and convenient to operate.
3. Desktop fixing frame
The machine can be quickly and conveniently fixed on the sitting or vertical workbench through the quick-locking parts.
4. Pedal design
Use foot pedals to free your hands for guiding materials
5. Pressing wheel
The operating handle can provide sufficient pressure to easily cope with the welding of materials of different thicknesses. Nozzles and pressing wheels of various sizes can be customized to meet the different needs of users.
