JZL Series Marine Cold Storage Axial Fan

Product Introduction:

JZL series axial fan impeller made of cast aluminum alloy has delicate and beautiful appearance with reliable use, low noise and high efficiency .

This product is widely used and is the supporting product of Marine refrigeration equipment. The fan is divided into 13 numbers according to the diameter of the impeller. Each number has five blade mounting angles, namely A, B, C,D, E. In this way, it can meet the usage requirements of different customers in a wide range, more use and more energy saving.

Parameters:

Number	Speed rpm	Blade Degree	Air Flow Rate (m3/h)	Total Pressure (Pa)	Noise Level (dB)	Motor
						Type	Power(kw)
JZL-2.8	2900	A	1592	141	58	YSF-562-2	0.12
		B/C/D	2095/2496/2820	151/156/168	61/62/62	YSF-562-2	0.18
		E	3092	216	65	YSF-632-2	0.25
	1450	A/B/C	798/1048/1247	35/38/39	52/53/53	YSF-501-4	0.03
		D/E	1414/1550	46/56	53/54	YSF-502-4	0.04
JZL-3.15	2900	A	2258	179	62	YSF-631-2	0.18
		B	2968	194	64	YSF-632-2	0.25
		C/D	3552/3998	197/222	65/66	YSF-711-2	0.37
		E	4388	274	68	YSF-712-2	0.55
	1450	A	1129	45	53	YSF-501-4	0.03
		B	1484/1777	48/49	53/54	YSF-502-4	0.04
		C/D	2001	55	55	YSF-561-4	0.06
		E	2195	69	56	YSF-562-4	0.09
JZL-3.55	2900	A	3250	224	66	YSF-711-2	0.37
		B/C	4273/5075	245/250	68/69	YSF-712-2	0.55
		D	5769	279	70	YSF-801-2	0.75
		E	6317	348	72	YSF-802-2	1.10
	1450	A	1622	56	54	YSF-502-4	0.04
		B/C	2132	59	55	YSF-561-4	0.06
		D	2537/2874	62/70	55/56	YSF-562-4	0.09
		E	3152	87	57	YSF-631-4	0.12
JZL-4.0	2900	A	4640	289	69	YSF-712-2	0.55
		B/C/D	6071/7265/8220	314/318/355	72/73/74	YSF-802-2	1.10
		E	9014	441	76	YSF-90S2	1.50
	1450	A	2323	72	55	YSF-562-4	0.09
		B/C	3053/3632	78/79	57/60	YSF-631-4	0.12
		D	4116	88	60	YSF-632-4	0.18
		E	4515	111	62	YSF-711-4	0.25
JZL-4.5	1450	A	3309	91	60	YSF-631-4	0.12
		B	4349	99	60	YSF-632-4	0.18
		C	5175	101	62	YSF-711-4	0.25
		D/E	5861/6428	113/140	62/64	YSF-712-4	0.37
JZL-5.0	1450	A	4538	114	60	YSF-711-4	0.25
		B/C	5965/7098	123/125	65/66	YSF-712-4	0.37
		D	8040	139	66	YSF-801-4	0.55
		E	8818	173	68	YSF-802-4	0.75
	960	A/B/C	2961/3914/4614	50/52/53	50/51.9/52.9	YSF-801-6	0.37
		D/E	5276/5786	61/77	60/62	YSF-801-6	0.37
JZL-5.6	1450	A	6368	141	64	YSF-712-4	0.37
		B	8368	154	67	YSF-801-4	0.55
		C	9972	155	68	YSF-802-4	0.75
		D/E	11279/11405	174/217	69/71	YT90S-4	1.10
	960	A/B/C	4076/5432/6484	56/64/66	58/60/60	YSF-801-6	0.37
		D/E	7622/8030	74/91	62/64	YSF-801-6	0.37
JZL-6.3	1450	A	9004	176	68	YSF-802-4	0.75
		B/C	11919	194	70	YT90S-4	1.10
		D	14199/16065	197/222	71/72	YT90L-4	1.50
		E	17372	274	75	YT100L1-4	2.20
	960	A/B/C	5895/7747/9231	76/80/83	60/62/63	YSF-801-6	0.37
		D/E	10442/11453	93/116	63/65	YT90S-6	0.75
JZL-7.1	1450	A	12980	227	72	YT90L-4	1.50
		B/C	16281/20237	245/250	74/75	YT100L1-4	2.20
		D	22670	283	76	YT100L2-4	3.00
		E	25575	358	79	YT112M-4	4.00
	960	A/B	8438/11091	97/102	62/65	YT90S-6	0.75
		C/D	13213/14948	106/118	66/67	YT90S-6	0.75
		E	16395	147	69	YT90L-6	1.10
JZL-8.0	1450	A	18572	289	76	YT100L1-4	2.20
		B/C	24409/29076	314/318	78/79	YT112M-4	4.00
		D	32898	355	80	YT132S-4	5.50
		E	36081	441	83	YT132M-4	7.50
	960	A	12070	123	66	YT90S-6	0.75
		B	15863	131	68	YT90L-6	1.10
		C/D	18899/20699	134/150	70/71	YT100L-6	1.50
		E	186	186	73	YT112M-6	2.20
JZL-9.0	960	A	18132	172	71	YT100L-6	1.50
		B	23830	191	73	YT112M-6	2.20
		C/D	28390/32119	196/211	74/75	YT132S-6	3.00
		E	35227	263	77	YT132M1-6	4.00
JZL-10.0	960	A	24874	213	74	YT112M-6	2.20
		B	32691	236	76	YT132S-6	3.00
		C/D	38941/44062	242/261	77/78	YT132M1-6	4.00
		E	48326	324	81	YT160M-6	7.50
JZL-11.2	960	A	34944	267	77	YT132M1-6	4.00
		B	45927	297	80	YT132M2-6	5.50
		C/D	54709/61901	304/337	80/82	YT160M-6	7.50
		E	67892	407	64	YT160L-6	11.00
