Product Description
Model | WGV900R | WGV1100R | WGV1500R | |
Total Height(mm) | 900 | 1100 | 1500 | |
Freeboard(mm) | 320 | 360 | 500 | |
Draught(mm) | 460 | 560 | 750 | |
Section Length (m) | 100 | 100 | 100 | |
Operational limits | Wave height(m) | 1 | 1.5 | 2 |
Current speed(kn) | 2 | 3 | 3 | |
Wind speed(m/s) | 15 | 20 | 20 | |
Weight(kg) | 5.5 | 7 | 10 | |
Reel measurement(mm) | 600(L)x3500(W)x4000(H) | 6000(L)x2350(W)x2800(H) | 4700(L)x2350(W)x2800(H) | |
Reel Weight(kg) | 4380 | 3580 | 2980 | |
Reel roll measurement(mm) | Ф3500x4800 | Ф2400x4800 | Ф2400x3800 |
