Marine LED Navigation Light Double-deck Navigation Signal Port Light CXH2-102PL

Origin: Made in China
Type: Port light
Power: LED 2*6W
For boat: More than 50M
Lamp holder: P28S
Protection class: IP66
Color: White, red, yellow, green etc
Working temperature: -30℃to 50℃
Delivery time: 3-15days
Brand: Deyuan Marine

Product Description

Marine LED Navigation Light Double-deck Navigation Signal Port Light CXH2-102PL
The scope of application:
Used for the ships with the length 50m or above 50m as lamp signal liaison when night navigation
Product characteristic:
1.The shell is made of high-strength engineering plastic PA+GF,the lampshade adopts injection of PC,lens hood adopts good quality stainless steel.
2.The signal lights have the whole seal structure,it is waterproof under the bad environment.
3.The connection of the signal light's lamp holder and the base adopt plug-in type,can replace the up and down bulb as open the cover.
4.The signal lights adopt the signal light’s bulb which conform to the ship norm,and average life is not lower than 700h
5.The signal lights can work normally under the temperature -30℃~55℃.
Adopt standard:
1.Conform to the international regulations for preventings collision at sea,1972 and Grade entry norms for steel ships
2.Confirm to the international standard IEC60598-1-2008
3.Confirm to the standard of marine electric signal light's technical condition GB/T3028-1995
Navigation light
Name Series Material  Available Light  Application
Navigation light
CXH101P Shell:Engineering Plastic PA+GF
Lens Hood:stainless steel
starboard light ,
port light,
masthead light,
stern light
all-round light
Applied to the ship with the
length 50M or above 50M as lamp signal liaison
CXH-10S Shell:Stainless steel
CXH-20S Shell:Stainless steel
Applied to the ship with the
length 12M or above 12M(<50M) as lamp signal liaison
Name/ TypeVisibilityLevel arcColor PowerWeight
CXH1-102PL Starboard light3n.m112.5ºGreen 2*6W6.2kg
CXH2-102PL Port light3n.m112.5ºRed2*6W6.2kg
CXH3-102PL Masthead light6n.m225ºWhite2*8W6.2kg
CXH4-102PL Stern light3n.m135ºwhite/Yellow2*6W6.2kg
CXH6-102PL All-roung light3n.m360ºRed/Green/White2*6W6kg
