Marine Breather Valve

Marine Breather Valve:

We can offer marine gate valve,marine globe valve,marine butterfly valve,marine check valve etc

Product standard:CB/T,GB/T,,JIS ,DIN ,API、ANSI,BS etc.

Technical Details:

DN (mm)	Structure dimension								thickness		oil tank flange
	H		H1		L		L1				connection
	A type	B	A	B	A	B	A	B	Cast iron	Cast steel	D	D1	D2	b	do
80/100	248	330	100	10	260	380	135	220	8	6	170	138	118	14	15
100/150	290	500	136	25	300	500	140	304	9	7	190	158	138	14	15
AS type &BS type
80/100	248	330	100	10	260	380	135	220	8	6	190	158	128	18	18
100/150	290	500	136	25	300	500	140	304	9	7	210	170	148	18	18
