Harbor Solid PVC Flotation Oil Boom

  • Deyuan Marine

Product Description

Harbor Solid PVC Flotation Oil Boom :
Model WGV600 WGV700 WGV750 WGV900 WGV1200 WGV1400
Freeboard 180mm 260mm 250mm 330mm 360mm 500mm
Draft 320mm 400mm 410mm 540mm 650mm 770mm
Length per section         20m
Max, working tensile strength 20 KN 40KN 55KN 65KN 80KN 120KN
Floating weight ratio 3.9 5.6 5.9 6.2 6.6 8
Weight 48kg 50kg 75kg 130kg 190kg/m 248kg
Max, wave height to withstand 0.5m 1m 1.5m 1.8m 2m 2.5m
Max, wind speed to withstand 10m/s 15m/s 15m/s 18m/s 20m/s 20m/s
Max, current speed to with stand 1 1.5 2 2Kn 2.5Kn 3.0Kn
Packing dimensions for 20m/60m 1*1*0.6 1.1*1*0.8 1.1*1.1*0.9 1.3*1.1*1.1 1.6*1.5*1.3 1.9*1.8*1.5
More Harbor Solid PVC Flotation Oil Boom Can Be Offered,Pls Contact Us For More Details.
