Flange Connection Stainless Steel Electric Marine Fire Monitor

Capacity: 360m3/h
Max.pressure: 16Bar
Materials: Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy
Rotation range: Horizontal: 340°;Vertical: +75°~ -45°
Inlet: Flange DN250 PN16; Flange DN300 / ANSI10'' optional
Outlet: Flange connection
Weight: ~550Kg

Product Description

SS250EL Flange Connection Stainless Steel Electric Marine Fire Monitor
Effective capacity:   32000L/min (around 534L/s,1920M3/H)
The max pressure:    16bar
Inlet:   Flange DN250 PN16
Outlet:   Flange connection
Optional inlet : Flange DN300 / ANSI10''
Rotation range:
Horizontal:  340°
Vertical:   +75°~ 45°
Weight:  ~550Kg
Materials:
Body:  Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy
Sealing:  NBR
Pipe:   Hard aluminum alloy
Flange:  Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy
Painting:   Red RAL3000
The monitor can be arrested in any horizontal or vertical position
