Yuchai YC4108C Series Marine Diesel Engine For Marine Fishing Boat

YC4108C series marine diesel engine is an ideal main engine power for 35~50meter marine fishing boat,passenger ships with tonnage of 3000~5000ton.ZY,ZC,CCS certificate and IMO certificate are available.This series of marine diesel engine can be serves as marine propulsion and auxiliary engine for vessels.

YC4108C、YC4108CA、YC4108ZC Marine Diesel Engine Technical Parameters

Model		YC4108C	YC4108CA	YC4108ZC
Type		Vertical, in-line, water-cooled,,4-stroke
Intake way		Natural aspiration		Gas turbo-charging
mm No. of cylinders		4*108*115
* Bore * Stroke
Displacement L		4.214
Compression ratio		17.1
Continuous power /speed（kW/r/min）		40/1500	32/1500	50/1500
One-hour power/speed（kW/r/min)	Main machine	44/1548	35.2/1548	55/1548
	Ancillary machine	44/1500	35.2/1500	55/1500
Min. specific fuel consumption(g/kW·h)		<218		<210
Specific oil consumption (g/kW·h)		<0.8
Crankshaft rotation direction		counterclockwise
(seen from power output end)
Net weight (kg)		370		390
Overall dimensions		986*730*948		986*730*1254
(L*W*H)  (mm)
Matched reduction gearbox		Hangzhou Qianjin Gearbox (models MB142, 40A, MB170, MBS170 etc.)
Specification of connection with the gearbox		Casing:SAE3#     Flywheel：11.5〞
Overhaul period		>10000 hours
