YYJH2000 Cooking Fume Purification And Deodorant Device

YYJH2000 Cooking Fume Purification And Deodorant Device

Product Introduction:

The YYJH2000 is a high‑efficiency, integrated cooking fume purification and deodorant system engineered specifically for marine and commercial kitchens where air quality, safety, and regulatory compliance are paramount. Designed to separate, purify, and deodorise cooking fumes in a single compact unit, it effectively removes oil particles, smoke, and odours – ensuring a clean, fresh, and safe environment for galley crews and passengers, even in confined shipboard spaces.

Marine‑Grade Stainless Steel Construction:

1.Full SUS304 stainless steel body – the entire housing and internal components are constructed from premium food‑grade 304 stainless, offering outstanding corrosion resistance against salt spray, high humidity, and aggressive grease deposits.

2.Compact, space‑optimised footprint – dimensions of 2200 × 1360 × 1540 mm fit neatly into standard galley ventilation spaces, making it suitable for ships, offshore platforms, and large commercial kitchens.

3.Reinforced, vibration‑resistant frame – heavy‑duty mounts and anti‑vibration brackets ensure stable operation even in rough seas, preventing misalignment and maintaining seal integrity.

Technical Specifications:

Intelligent Control – Fully Automatic & Manual Operation:

1.The device features a smart control system with both automatic and manual modes, offering flexibility for different operational needs:

2.Auto mode – built‑in smoke concentration sensors automatically start and stop the unit based on real‑time fume levels, optimising energy consumption and filter life.

3.Manual mode – allows crew to override the system for continuous operation during peak cooking periods.

4.Emergency override function – if the main purification system fails, a dedicated emergency fan can be started independently to ensure uninterrupted smoke extraction – critical for fire safety and crew comfort.

Automated Self‑Cleaning & Waste Disposal:

1.One‑touch automatic cleaning – initiates a complete wash cycle for the internal purification cells with a single button, eliminating the need for manual dismantling and scrubbing.

2.Automatic waste discharge – after each cleaning cycle, contaminated wastewater is automatically drained through the dedicated R1/2 outlet, reducing maintenance labour and ensuring consistent purification efficiency.

3.Intelligent delay shut‑off – upon shutdown, the system continues to run for 30 seconds to expel any residual fumes, ensuring the kitchen is completely clear of smoke before the unit powers down.

Comprehensive Safety & Protection Systems:

The YYJH2000 is equipped with multiple fail‑safe protections, making it one of the safest ventilation systems for marine use:

*Leakage protection – instant shutdown in case of electrical leakage.

*Over/under‑voltage protection – safeguards sensitive electronics from unstable shipboard power.

*Overload protection – prevents motor burnout during heavy‑load conditions.

*Phase‑loss & phase‑sequence protection – ensures the motor rotates in the correct direction, preventing damage and maintaining airflow.

High Purification Efficiency & Low Noise:

*≥95% purification rate – effectively removes grease particles, smoke, and odours, meeting stringent environmental and health regulations for marine and onshore kitchens.

*6000 m³/h air output – delivers powerful suction for large‑scale cooking operations, handling multiple stoves and fryers simultaneously.

*Low‑noise operation (68 dB) – quiet enough for open‑plan galleys and passenger‑adjacent areas, minimising noise pollution without compromising performance.

Data Monitoring & Full Life‑Cycle Management:

1.Real‑time data logging – continuously collects and stores operational data and fault records, including runtime, cleaning cycles, filter status, and error events.

2.Statistical analysis for predictive maintenance – by analysing accumulated data, operators can schedule maintenance proactively, extending equipment life and reducing unexpected downtime.

3.Fault diagnosis & alarm – visual and audible alerts notify crew of any abnormal conditions, enabling rapid response and repair.

Conclusion:

The YYJH2000 Marine Cooking Fume Purification and Deodorant Device combines robust stainless‑steel construction, intelligent sensor‑based operation, and automated self‑cleaning to deliver reliable, efficient, and low‑maintenance air purification for marine and commercial kitchens. Its high purification rate, comprehensive safety protections, and real‑time data management make it the ideal solution for ensuring clean air, regulatory compliance, and long‑term reliability in the most demanding seagoing environments.
