CWF Series 10m3/h Marine Horizontal Crushing Pump

Series: CWF
Structural style: Vertical
Voltage: 50HZ,3ะค,380V
Capacity: (5,6,10)m3/h
Pump head: (10,13,15,18,20,25,30)m
Speed: 2900/3500rpm
Power: 1.1~5.5KW

Product Description

CWF Series Marine Horizontal Crushing Pump
1. Smash pump emissions open impeller centrifugal pump
2. Used in the temperature lower than 85 degrees of sewage soft qualitative sewage cutting and transportation
3. Suitable for use in Marine heavy oil at low temperature solidification, Easy to spray

Type (50HZ,3phase,380V) main technical parameter Motor power(kw)
Capacity Head Speed NPSHR Shaft power(kw)
(m3/h) (m) (r/min) (m)
0.5CWF-10 5 10 2900 3.5 0.65 1.1
0.5CWF-15 5 15 2900

1.5
0.5CWF-15A 5 13 2900

1.1
0.5CWF-20 5 20 2900

1.5
0.5CWF-20A 5 18 2900

1.5
0.5CWF-25 5 25 2900

1.1
0.5CWF-30 5 30 2900

1.5
1CWF-10 10 10 2900

1.5
1CWF-15 10 15 2900

2.2
1CWF-20 10 20 2900

3
1CWF-25 10 25 2900 3.8 2.3 4
1CWF-30 10 30 2900

5.5
0.5CWF1-10 6 14.5 3500


0.5CWF1-15 6 21.5 3500


0.5CWF1-15A 6 18.5 3500


0.5CWF1-20 6 29 3500


0.5CWF1-20A 6 26 3500


0.5CWF1-25 6 36 3500


0.5CWF1-30 6 43 3500


More types can be offered,pls contact us for more details.
