Product Description
Model /Parameter | WQJ1000 |
Overall height | 1000mm |
Freeboard | 360mm |
Draft | 430mm |
Max, working tensile strength | 140mm |
Standard length per section | 100/200m |
Max, wave height to withstand | 2m |
Max, wind speed to withstand | 15m/s |
Max, current speed to with stand | 3KN |
Standard connector | ASTM or Stainless steel hinge or pin |
Dimension of reel frame | 2000x2200x2013mm |
Drive power of power pack | 14.5kw |
Dimensions of container | 2900x2200x2200mm |
