Marine Hydraulic Single Drum Anchoring Winch with Warping Drum

Place of Origin: China
Driven: Hydraulic
Working Load: 30KN
Norminal Speed: 10m/min(1*layer)
Rope dia.: 30mm
Transport Package: Export standard
Certificate: CCS, BV, ABS, DNV, KR, NK, RINA, GL, LR
  • Deyuan Marine


Product Description

Marine Hydraulic Single Drum Anchoring Winch with Warping Drum

A mooring winch is one of the marine equipment used during mooring operations to hold a boat in place at a pier or similar fixture. Such marine mooring winches may also be able to control anchors for mooring when port facilities are not available.

A mooring winch with anchoring functin(anchor operation), means need more power to realize anchoring than a normal mooring winch, higher safety factor.

Normally the drum of an anchoring winch will accommodate wire rope and a short length of anchor chain.

Wire rope transmit strength from the winch to the anchor chain, finally to the anchor, so the chain will connect with the wire rope and the anchor.

The marine moorning winch can operate effectively when dockship or docking port, and it has many functions. In the process of loading and unloading, it plays the role of drift, support and positioning, and adjusts the deviation of compensation vibration with constant tension.

The below hydraulic marine moorning winch is with the rated pull as 15Ton, with one durm. Deyuan marine can offer you the other type marine mooring winch with different pull and follow up your detailed requirement.

All our marine mooring winchs are approved by CCS,ABS,DNV,BV,NK,RINA,BKI. Deyuan marine can offer you all kinds of winch with hight quality and best price.

Pls feel free to contact deyuan marine sales team for more details.

15Ton Marine Hydraulic Driven One Drum Mooring Winch

Marine Mooring Winch Specification

Type Single drum with a dog clutch capstan

Rated load

Rated speed 10m/min
 Holding load Wire braking load278Kn
Dia wire 30mm
Drum capacity 220mtrs wire and 10mtrs 38mm chain

More Marine Hydraulic Single Drum Anchor Winch With Capstan can be offered,pls contact us for more details.
