Product Description
HKD-2XK Marine Amplifier for Marine Public Address System
Product Introduction
Designed specifically for the demanding environment of modern passenger vessels, this Marine Public Address Amplifier serves as the critical audio core for onboard safety and communication. Fully compliant with SOLAS, IMO, and relevant classification society standards, it ensures reliable transmission of emergency announcements, general information, and entertainment audio across all designated zones. Engineered with robust, corrosion-resistant materials, the amplifier withstands constant vibration, humidity, and temperature fluctuations.
The system features high-powered output with clear priority overrides, allowing bridge announcements to instantly interrupt background music. It offers modular design for easy expansion, integrated monitoring for fault detection, and seamless compatibility with existing shipboard alarm and control systems. With redundant power inputs and intuitive controls, this amplifier guarantees continuous, crystal-clear communication for crew directives and passenger safety—an indispensable component for any ferry, cruise ship, or ocean liner.
Drawing
Technical Data
| Color | White |
| IP Class | IP20 |
| Material | Steel |
| Installation | Cabinet Type |
| Rated Output Power | 2x50W,2x100W,2x200W,2x400W,The Output Form Of the Power Amplifier ls Constant Voltage AC120V |
| Nonlinear Distortion<7%At Rated Output Power | |
| Frequency Response(100Hz-8KHz) | ≤3dB |
| Weight | ≥43.5kg |
| Main Power | Two Way AC220V±10% |
| Emergency Power | Two Way DC24V (+30%~-25%) |
HKD-2*□K/2*□T Marine Public Address System
HKD-2*□K/2*□T Marine Public Address System Connection Diagram
HKD-D Marine Public Address System
HKD-D Marine Public Address System Connection Diagram
