CB/T 498-95 Mooring Synthetic Fiber Rope Reel Deck Mounted Rope Storage or Rope Winder

Type: Mooring Rope Reel
Brand: Deyuan Marine
Material: Cast steel, carbon steel, cast iron, aluminium, stainless steel
Standard: ​CB/T 498-95
Rope Dia.: 30mm-72mm
Certificates: CCS, ABS, GL, NK, BV, LR, DNV, RINA
Warranty: 12 months

Product Description

CB/T 498-95 Mooring Synthetic Fiber Rope Reel Deck Mounted Rope Storage or Rope Winder


Mooring Synthetic Fiber Rope Reel is used for marine rope storage and containment on ships' deck / deck mounted rope storage.

Specifications:
Drive: Hand / Electric / Hydraulic
Configuration: single drum
Wire drum: steel wire rope / fiber rope drum
Rated pull (1st layer): 2 to 20MT
Wire speed: up to 30m/min
Control: local control
Design service: offered
Warranty: 12 months
Third Party Certificates: CCS, ABS, GL, NK, BV, LR, DNV, RINA
Delivery: 20 days for marine mooring rope reel, upon your order quantity.
Package: Wooden Case for Rope Winder, or with pallets.


CB/T 498-95 Marine mooring rope reel is a special purpose winch. We also can provide other special purpose winches, including streamer winch, gun winch, wire spooling winch, auxillary pulling winch. We provide custom-made
solution to meet special offshore applications.


CB/T 498-95 Mooring Synthetic Fiber Rope Reel Deck Mounted Rope Storage or Rope Winder

DIA(mm)  D D1 D2 L L1 B B1 H
30 190 650 820 750 930 650 630 520
34 190 650 820 860 1046 650 630 520
38 190 650 820 880 1056 650 630 520
42 255 810 980 850 1046 820 650 575
46 255 810 980 930 1126 820 650 575
50 325 970 1140 910 1108 980 800 655
54 325 970 1140 930 1128 980 800 655
60 405 1150 1320 905 1108 1140 800 745
72 490 1330 1500 920 1132 1310 1020 830
