Product Description
A60 Class Single Leaf Fireproof Door CFM-1ZA
Product Introduction:
The A60 Class Single Leaf Fireproof Door is a high-performance marine-rated fire door designed to meet stringent SOLAS (Safety of Life at Sea) and IMO (International Maritime Organization) requirements. It provides reliable A60 fire protection in a compact, single-leaf configuration, making it an ideal solution for bulkhead openings on ships, offshore platforms, and marine vessels where fire safety is critical but space is limited.
Product parameters:
| Door leaf | PVC laminated/powder coated steel sheet |
| Door frame | Steel plate |
| Powder coated | |
| Stainless steel door sill cover plate | |
| Max clear open size | 1200×2500 |
| Cutting size | 1252×2552 |
| Size of door | 1404×2704 |
| Open direction | LO/RO/LI/RI |
| Door leaf thick | 40mm |
| Sound reduction value(db) | 38dB |
| Sill | √ |
| Optional fitings | / |
Key Features:
*A60 Fire Rating – Certified to withstand fire for 60 minutes, preventing flame passage and limiting heat transmission in accordance with IMO FTP Code Part 3.
*Single Leaf Design – Compact and space-efficient, ideal for narrow passageways, cabin entrances, and corridor bulkheads where double leaf doors are impractical.
*Heavy-Duty Steel Construction – Fabricated from high-strength steel with a ceramic or mineral fibre insulation core to maintain structural integrity under fire conditions.
*Self-Closing Mechanism – Equipped with an automatic closing device to ensure the door closes securely in the event of fire or emergency, complying with SOLAS Chapter II-2 requirements.
*Corrosion-Resistant Finish – Protected with hot-dip galvanising, epoxy coating, or marine-grade paint for long-term durability in saltwater and humid marine environments.
*Approved Fire Seals – Integrated intumescent seals that expand under heat to block smoke and flames, ensuring full fire compartment integrity.
*Reliable Hardware – Heavy-duty stainless steel hinges, latches, and handles designed for frequent operation and emergency conditions.
Typical Applications:
*Ship interior and exterior bulkheads.
*Offshore drilling rig accommodation areas.
*Naval vessel corridor and cabin doors.
*Ferry and cruise ship fire zones.
*Marine industrial facilities requiring A60 fire protection.
Why Choose This Door?
The A60 Class Single Leaf Fireproof Door delivers uncompromising fire safety in a space-saving design. For shipbuilders and marine operators who need certified A60 protection without the footprint of a double leaf door, this is the reliable, code-compliant solution.
